1
Engine displacement
1000
2
Year
2022
3
Trim
RANGER CREW XP 1000 HIGH LIFTER
4
Parts Catalog
BODYWORK
5
Parts Diagram
Parts Catalog
BODYWORK
by
TAILGATE
BODYWORK
1
2
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
1
WELD-BOX LATCH BLK
1026726458
2209726
$241,80 Unit Price incl. VAT
2
SCR-TXTH-M6X1.0X25 ZFB
7519650
$7,34 Unit Price incl. VAT
3
SCR-M8X1.25X50 HX/FL-Y
7517793
$10,49 Unit Price incl. VAT
4
SCR-TXPH-#14X5/8 HI/LO CLR
7520803
$6,29 Unit Price incl. VAT
5
RIVET-POP 3/16 (.376-.500) AL-LFB
7621460
$2,09 Unit Price incl. VAT
6
WELD-BOX SUPPORT HVAC BLK
1026798329
1028367-329
$629,99 Unit Price incl. VAT
7
BUMPER-BOX [FROM 08/01/2023]
5414343
$10,49 Unit Price incl. VAT
8
BUSHING-BOX LATCH
5434226
$7,34 Unit Price incl. VAT
9
HANDLE BOX LATCH
5450278
$62,99 Unit Price incl. VAT
10
SHIELD-BOX CARGO MUD
5271549
$246,74 Unit Price incl. VAT
11
SHOCK-BOX DUMP RGR 441MMEXT
7045663
7046185
$125,99 Unit Price incl. VAT
12
SCR-HXFL-M10X1.25X80 8.8 ZOD
7519363
7528444
$4,19 Unit Price incl. VAT
13
NUT-M8X1.25 HXFLG NYLON INS
7547317
7548028
$5,24 Unit Price incl. VAT
14
NUT-M10X1.25 FLG NYLOC-OLIVE D
7547333
$3,14 Unit Price incl. VAT
15
CLIP-HITCHPIN .148X3 1/16
7661067
$4,19 Unit Price incl. VAT
16
PIN-CLEVIS 1/2 X 1 3/4
7661878
$4,19 Unit Price incl. VAT
17
SPRING-EXHAUST
7041687
$12,59 Unit Price incl. VAT
18
SHIELD-BOX SILENCER HVAC
5264681
$99,74 Unit Price incl. VAT
19
ROLLER-CAM LATCH
5458307
$10,49 Unit Price incl. VAT
20
NUT- M8X1.25 FLG NYLOC-OLIVE D
7547332
$7,34 Unit Price incl. VAT
21
WASHER-8.4X24.0X2.0 ZPB
7556045
$16,79 Unit Price incl. VAT
22
SCR-HXFL-M8X1.25X70 10.9 ZFB
752133270
$7,34 Unit Price incl. VAT
23
SCR-TFHFL-M8X1.25X20 CHS ZOD
7518555
$4,19 Unit Price incl. VAT
24
BRKT-SPACER LH ECOAT
5271905329
$52,49 Unit Price incl. VAT
25
BRKT-SPACER RH ECOAT
5271906329
1029757-329
$104,99 Unit Price incl. VAT
26
BRKT-PLATE CAM HVAC ECOAT
5271928329
$73,49 Unit Price incl. VAT
27
BUMPER-LOCATING HVAC [TO 06/05/2023]
5417793
$73,49 Unit Price incl. VAT
28
SCR-RHCAR-M8X1.25X85 8.8 ZPB
7520351
$13,64 Unit Price incl. VAT
29
SCR-HFH-M8X1.25X20 TAP/R ZPB
7519780
$9,44 Unit Price incl. VAT
30
CAP-BUMPER
5434191
$12,59 Unit Price incl. VAT
31
WELD-BUMPER REAR INDY RED
1023593293
$456,74 Unit Price incl. VAT
32
WELD-MNT RR BUMPER INDY RED
1023811293
$141,74 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
