Parts Catalog
ENGINE MOUNTING
5
Parts Diagram
Parts Catalog
COOLING SYSTEM
by
FRONT WHEEL
ENGINE MOUNTING
1
2
3
3
3
3
3
3
3
4
5
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
19
20
21
22
23
23
24
25
26
27
27
28
29
29
30
31
32
33
34
35
36
36
37
37
38
39
40
41
41
42
43
44
1
2
3
3
3
3
3
3
4
5
5
6
7
8
9
10
11
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
13
14
14
14
15
15
16
17
18
1
Asm. Fuel Pump [Incl. 1-4]
3085275
2520227
$146,99 Unit Price incl. VAT
2
NUT-M5X.8 HX NYL-Y
7546601
$2,09 Unit Price incl. VAT
3
HOSE CLAMP RED
7080003
$2,09 Unit Price incl. VAT
4
FUEL LINE-1/4 ID (SVC) 600 CM [BULK]
8450040600
$136,49 Unit Price incl. VAT
5
Line Fuel
8450103
8450117-250
$99,74 Unit Price incl. VAT
6
SCREW
3130535
$13,64 Unit Price incl. VAT
7
COVER
3130511
$83,99 Unit Price incl. VAT
8
O-RING
3130512
Not Available
9
HOSE [BULK SVC]
84500031525
$136,49 Unit Price incl. VAT
10
HOSE-POLY CLEAR 3/16 OD 1/8 ID
8360009600
$83,99 Unit Price incl. VAT
11
FILTER
2530009
$12,59 Unit Price incl. VAT
12
ENG.(S.B.)EH50PLE-01 (EH50PLE03) NOTE: The Short Block assembly contains a crankcase assembly cylinder and cylinder head assembly and a piston & crankshaft assembly. Prior authorization require
3085556
Not Available
13
CABLE GUIDE MIKUNI BTM36/30
3130543
$62,99 Unit Price incl. VAT
14
Cable Throttle
7080967
$104,99 Unit Price incl. VAT
15
O-RING
5410193
$7,34 Unit Price incl. VAT
16
Mount Engine Top
5242936067
$9,23 Unit Price incl. VAT
17
CABLE GND-ENGINE
4010132
Not Available
18
WASHER-5/16 SPRING LK-MED-Y
7552901
$2,09 Unit Price incl. VAT
19
Bolt
7512315
$9,44 Unit Price incl. VAT
20
WASHER-.390X1.12X.060 FL-Y
7555823
$7,34 Unit Price incl. VAT
21
Spacer
5132007
Not Available
22
Mount Rubber
3021045
Not Available
23
NUT FLANGE LOCK
7547108
$9,44 Unit Price incl. VAT
24
NUT FLANGE(10)
3083649
$7,34 Unit Price incl. VAT
25
Cable Battery/Engine
4010095
Not Available
26
CABLE-21# SOL/START RED
4010093
$89,24 Unit Price incl. VAT
27
Boot Clutch Intake (If built after 8/04/03)
5412487
Not Available
27
BOOT CLUTCH INTAKE
5410421
$20,99 Unit Price incl. VAT
28
CLAMP-NARROW BAND 1.38/2.38
7080511
$9,44 Unit Price incl. VAT
29
WASHER FLAT
7555815
$7,34 Unit Price incl. VAT
30
Mount Rubber Rear
3021119
Not Available
31
COIL IGNITION (Incl. 1 2)
3084690
Not Available
32
CDI-SYSTEM (S#99-02080 & after)
3087169
Not Available
33
SWITCH MAGNETIC *
3087196
4011335
$115,49 Unit Price incl. VAT
34
SCREW & WASHER(10)
3084205
$7,34 Unit Price incl. VAT
35
ASM. BOLT AND WASHER
3082038
$7,34 Unit Price incl. VAT
36
Cable Choke (If built after 8/11/03)
7081176
7081008
$152,24 Unit Price incl. VAT
36
Cable Choke
7081008
$152,24 Unit Price incl. VAT
37
SCR-3/8-24X2 3/4HX HD CP GR5-Y
7515417
$9,44 Unit Price incl. VAT
38
Mount Rubber
3110044
3024012
$83,99 Unit Price incl. VAT
39
Bracket Torque Stop
5245043
$31,49 Unit Price incl. VAT
40
Mount Engine Lower Front
5242818067
$51,54 Unit Price incl. VAT
41
WASHER LOCK (10)
3080530
$6,29 Unit Price incl. VAT
42
NUT(10)
3080285
Not Available
43
Manifold
1260978029
Not Available
44
GASKET EXH.
3085075
$73,49 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
