1
Engine displacement
0
2
Year
1996
3
Trim
CLASSIC TOURING - 0963365
4
Parts Catalog
NOSEPAN CLASSIC TOURING 0963365 and EUROPEAN CLASSIC TOURING E963365 (4933623362A011)
5
Parts Diagram
Parts Catalog
by
NOSEPAN CLASSIC TOURING 0963365 and EUROPEAN CLASSIC TOURING E963365 (4933623362A012)
NOSEPAN CLASSIC TOURING 0963365 and EUROPEAN CLASSIC TOURING E963365 (4933623362A011)
1
1
1
2
3
3
4
5
6
7
8
8
9
10
11
11
12
13
14
15
15
15
15
16
17
18
19
20
20
21
22
23
24
25
26
27
28
29
30
31
31
31
31
32
33
34
35
36
36
37
37
38
39
40
41
42
43
44
1
1
1
2
3
3
4
5
6
7
8
8
9
10
11
11
12
13
14
15
15
15
15
16
17
18
19
20
20
21
22
23
24
25
26
27
28
29
30
31
31
31
31
32
33
34
35
36
36
37
37
38
39
40
41
42
43
44
1
1
2
3
3
4
5
1
FOIL TOP OUT.SIDEPANEL
5811075
Not Available
2
FOIL UP.SIDEPANEL
5811073
Not Available
3
FOAM-FOIL RH SIDEPANEL
5811070
Not Available
4
BUMPER RH SIDE/FOIL BLK.MT.
2610010177
Not Available
5
FOIL SIDE BUMP UPPER
5811084
Not Available
6
FOIL SIDE BUMP MIDDLE
5811086
Not Available
7
FOIL TOP INNER SIDEPANEL
5811074
Not Available
8
FOIL FR.SIDEPANEL
5811072
Not Available
9
PANEL RH SIDE FOIL BLK.
2610008177
Not Available
10
COVER CONSOLE
5431535
Not Available
11
WASHER(10) Substituted by 7558301
7555776
7558301
$2,09 Unit Price incl. VAT
12
SCREW(10)
7512252
Not Available
13
RIVET PLASTI-LOC
7621509
$2,09 Unit Price incl. VAT
14
NUT RETAINER(10)
7542138
Not Available
15
CONSOLE BASIC
5431467
Not Available
15
CONSOLE EUROPE
5431697
Not Available
16
WASHER-.20X.67X.048-Y
7555792
$9,44 Unit Price incl. VAT
17
SCREW(10)
7512069
Not Available
18
RETAINER HOODLATCH
5431502
$23,09 Unit Price incl. VAT
19
WASHER RUBBER(10)
7555884
$9,44 Unit Price incl. VAT
20
SCR-PHPHD-10-24X0.5 GR2 ZY3
7512068
$4,19 Unit Price incl. VAT
21
NUT WELL
7541923
$10,49 Unit Price incl. VAT
22
BUMPER SIDE PANEL Substituted by 5432456
5431662
Not Available
23
FOIL LH SHOCKTOWER #12
5811188
Not Available
24
FOIL-CENTER #11
5811187
Not Available
25
FOIL RH SHOCKTOWER #13
5811192
Not Available
26
FOIL RH SHOCKTOWER TOP #14
5811193
Not Available
27
FOIL RH SHOCK TOWER LOW.
5811194
Not Available
28
FOIL RH PANSIDE #16
5811195
Not Available
29
SCREW
7512279
$1,56 Unit Price incl. VAT
30
NOSEPAN (EV W/BATT.)
5432045
Not Available
31
FOAM LH SIDEPANEL
5811076
Not Available
31
PANEL LH SIDE BLK.MET.
5431742177
Not Available
32
RIVET(50)
7621315
Not Available
33
BUMPER RUBBER STOP Substituted by 5411440
5410843
Not Available
34
RIVET BURR(50)
7555756
Not Available
35
SCR-1/4-20X5/8 TXTR GR5 P-5-Y
7515148
$9,44 Unit Price incl. VAT
36
RIVET
7621467
$2,09 Unit Price incl. VAT
37
WASHER FLAT
7558212
$1,56 Unit Price incl. VAT
38
BUMPERSIDE LH BLK.
5431492177
Not Available
39
PLUG NOSEPAN HOLE
5410820
$26,24 Unit Price incl. VAT
40
COVER F.BUMP.BOTTOM
5431481
Not Available
41
FOIL TAPE 3#DIA.
5810999
Not Available
42
PLUG CLUTCH HOLE
5410582
$15,74 Unit Price incl. VAT
43
COVER F.BUMP.TOP BLK.
5431480177
Not Available
44
FOIL SIDE BUMP LOWER
5811085
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
