1
Engine displacement
800
2
Year
2016
3
Trim
800 AXYS SKS 155
4
Parts Catalog
REAR BUMPER, SNOWFLAP AND TAILIGHT COVER
5
Parts Diagram
Parts Catalog
FRONT BUMPER
by
DECALS, WHT/RED, RED/WHT OPT.
REAR BUMPER, SNOWFLAP AND TAILIGHT COVER
1
1
1
2
3
4
5
5
6
6
6
7
7
2
9
10
10
10
11
12
12
12
13
14
15
16
17
1
COVER-TAILLIGHT HARNESS 155 NATURAL [COLOR OPTION]
5259599
$52,49 Unit Price incl. VAT
1
COVER TAILLIGHT HARNESS 155 MATTE BLK
5259599458
$120,74 Unit Price incl. VAT
1
COVER TAILLIGHT HARNESS 155 ORANGE BURST
5259599647
$120,74 Unit Price incl. VAT
2
RIVET-4.8MM DIA-1.5-6.0GRIP BK
7662251
$3,66 Unit Price incl. VAT
3
RIVET
7621433
$2,09 Unit Price incl. VAT
4
COVER TAILLIGHT BLACK
5452369070
$20,99 Unit Price incl. VAT
5
NUT-HXFL-M6X1.0 8 ZC NYL
7547487
$4,19 Unit Price incl. VAT
5
NUT-HXFL-M6X1.0 8 ZB3 NYL
7547453
$7,34 Unit Price incl. VAT
6
ASM. BUMPER REAR ALUM [INCL. 7 8 10 11]
1017851
1017851-309
$209,99 Unit Price incl. VAT
6
ASM. BUMPER REAR MATTE BLK [INCL. 7 8 10 11]
1017851458
$220,49 Unit Price incl. VAT
6
ASM. BUMPER REAR AL MBLK/ORNGBST [SNOW CHECK][INCL. 7 8 10 11]
10178511448
$241,49 Unit Price incl. VAT
7
PLUG TUBE
7081210
$7,34 Unit Price incl. VAT
7
CAP BUMPER
5137460
$52,49 Unit Price incl. VAT
8
RIVET-4.8MM DIA-1.5-6.0GRIP BK
7662251
$3,66 Unit Price incl. VAT
9
SCR-TXPH-M6X1.0X25 8.8 ZC
7519248
$6,29 Unit Price incl. VAT
10
MOUNT BUMPER ORBURST [SC SELECT OPTION]
5137501647
$89,24 Unit Price incl. VAT
10
MOUNT BUMPER
5137501
$73,49 Unit Price incl. VAT
10
MOUNT BUMPER MATTE BLACK
5137501458
$83,99 Unit Price incl. VAT
11
TUBE BUMPER ALUM. MATTE BLACK
5339046458
$120,74 Unit Price incl. VAT
12
ASM. CLOSEOFF TUNNEL MOUNT REAR MATTE BLK
1021963458
$74,54 Unit Price incl. VAT
12
ASM-CLOSEOFF TUNNEL MOUNT REAR [COLOR OPTION]
1021963
$74,54 Unit Price incl. VAT
12
ASM. CLOSEOFF TUNNEL MOUNT REAR ORNG BURST
1021963647
Not Available
13
RIVET-3/16-.090-.290
7661637
$2,09 Unit Price incl. VAT
14
RIVET
7621467
$2,09 Unit Price incl. VAT
15
FLAP-SNOW
5451976070
2208364
$89,24 Unit Price incl. VAT
16
WSHR-5.3X10X1 ZB
7556071
$9,44 Unit Price incl. VAT
17
NUT-ACORN M5 BLK
7547286
$6,29 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
