1
Engine displacement
500
2
Year
2002
3
Trim
500 RMK 136
4
Parts Catalog
CYLINDER
5
Parts Diagram
Parts Catalog
CRANKCASE
by
WATER PUMP/OIL PUMP
CYLINDER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1
SCREW M8X1.25X60(10)
7517534
$8,39 Unit Price incl. VAT
2
SCREW-M6X1.0X20-HX/FL-Y/D
7516822
$4,19 Unit Price incl. VAT
3
SCREW
7517679
$25,19 Unit Price incl. VAT
4
WASHER-FLAT 6.15X12X1MM-AL
7555998
$2,09 Unit Price incl. VAT
5
SENSOR TEMP 93 DEG.C.
4110254
Not Available
6
COVER-THERMOSTAT M6 BLEED LG
5630992
Not Available
7
O-RING
5411521
$36,74 Unit Price incl. VAT
8
Cover Head
5631198329
Not Available
9
O-RING-.924X1.130X.103 V/N-119
5411411
$1,56 Unit Price incl. VAT
10
SEAL MLDD.HEAD TWIN
5411465
$57,74 Unit Price incl. VAT
11
HEAD-CYLINDER 70.5 TWN SNO 3/4
3021048
$318,14 Unit Price incl. VAT
12
O-RING
5411199
$18,89 Unit Price incl. VAT
13
O-RING 4.739X4.879X.07
5411359
$23,09 Unit Price incl. VAT
14
NUT-M10X1.25-HX/FL
7547013
$3,14 Unit Price incl. VAT
15
CYLINDER 70.5MM SNO IRON
3021135
$583,79 Unit Price incl. VAT
16
GASKET-CYLINDER BASE
5811916
$36,74 Unit Price incl. VAT
17
FITTING-3/4NPT-1#HOSE BRASS Substituted by 7052313
7052234
$73,49 Unit Price incl. VAT
18
THERMOSTAT-50C TBYS SS STEM
7052267
Not Available
19
SCR-M6X1.00X40-HX/FL-Y/D [A15B1 B7]
7516818
$10,49 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
