1
Engine displacement
150
2
Year
2017
3
Trim
ACE 150
4
Parts Catalog
WHEELS, FRONT TIRE AND BRAKE DISC
5
Parts Diagram
Parts Catalog
REFERENCES, TOOL KIT AND OWNERS MANUAL
by
PARKING BRAKE BRAKE HANDLE
WHEELS, FRONT TIRE AND BRAKE DISC
1
WELD-RIM FRONT 10X5.5 BLK
1523018067
$211,04 Unit Price incl. VAT
2
TIRE-22X7-10 P3018
5416079
$130,71 Unit Price incl. VAT
3
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
4
COVER-FRONT HUB
5416088
$18,89 Unit Price incl. VAT
5
NUT-M10X1.25 FLG NYLOC-OLIVE D
7547333
$3,14 Unit Price incl. VAT
6
DISC-BRAKE FRONT
1912809
$141,74 Unit Price incl. VAT
7
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
8
BEARING-WHEEL 6204-RS
3514993
$47,24 Unit Price incl. VAT
9
BEARING-WHEEL 6202-2RS
3514994
$47,24 Unit Price incl. VAT
10
HUB-WHEEL FRONT
5140868
$194,24 Unit Price incl. VAT
11
PIN COTTER
7661203
$2,09 Unit Price incl. VAT
12
SCR-HXFL-M6X1.0X16 8.8 ZYL NYL
7519236
$6,29 Unit Price incl. VAT
13
STUD-M10X1.25X35.5
7520745
$9,44 Unit Price incl. VAT
14
WASHER-.560X1.10X.110 Y
7556336
$26,24 Unit Price incl. VAT
15
NUT-M14X1.5 CASTLE
7547859
$13,64 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
