SEAT ASM. AND SLIDER FOR RZR XP 1000 INTL FROM 2015

SEAT ASM. AND SLIDER

1

FRAME SEAT [AR][AU]

1019447

$362,24 Unit Price incl. VAT

2

ASM. SEAT BACK BLACK/SILVER [AT][AV][AP][AU][NV][NW]

2686247

$824,24 Unit Price incl. VAT

3

ASM. SEAT BOTTOM BLACK/SILVER [AT][AV][AP][AU][NV][NW]

2686248

Not Available

4

SCREW-1/4-20x3/4 BH TRX GR5-Z

7515177

$5,76 Unit Price incl. VAT

5

ASM. BASE SEAT SLIDER [INCL. 6-15 27]

2685704

$388,49 Unit Price incl. VAT

6

ASM. BASE SEAT [INCL. 6-12 27]

2634889

$246,74 Unit Price incl. VAT

7

PLATE-LATCH SEAT

5258647

$12,59 Unit Price incl. VAT

8

GROMMET SEAT BASE

5413441

$7,34 Unit Price incl. VAT

9

HANDLE-SEAT BASE LATCH

5437121

$9,44 Unit Price incl. VAT

10

SPRING LATCH SEAT

7081466

$57,74 Unit Price incl. VAT

11

SCREW-M6X1.00X40-HX/FL-YD

7517610

$3,14 Unit Price incl. VAT

12

NUT-6MM X 1 NYLOK-Z

7546703

$2,09 Unit Price incl. VAT

13

BRACKET SEAT SLIDER ADJUSTABLE PLATE

5257975

$31,49 Unit Price incl. VAT

14

SCR-RHCARM6X1.0X20 8.8 ZOD

7518994

$6,29 Unit Price incl. VAT

15

NUT-M6X1.0 FLG-NYLOC-OLIVE D

7547339

$2,09 Unit Price incl. VAT

16

BRACKET SEAT SLIDER MOUNTING PLATE [INCL. 16-20 FOR FRONT SEAT ONLY]

5257974

$120,74 Unit Price incl. VAT

17

BRACKET SEAT SLIDER LEVER

5260101

$52,49 Unit Price incl. VAT

18

SPRING

7044099

$10,49 Unit Price incl. VAT

19

SCR-SH-M6X1.0X9.5 12.9 ZY3

7518786

$4,19 Unit Price incl. VAT

20

BOLT SHOULDER

7518897

$3,14 Unit Price incl. VAT

21

TUBE SPACER

5337939

$10,49 Unit Price incl. VAT

22

SCR-1/4-20X1-BH-TRX-GR5-Z

7519296

$3,14 Unit Price incl. VAT

23

WASHER SPRING LOCK

7552801

$3,14 Unit Price incl. VAT

24

WASHER-FL .281X.750X.062-Y

7555859

$2,09 Unit Price incl. VAT

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
