1
Engine displacement
600
2
Year
1994
3
Trim
600 XCR - 0941667
4
Parts Catalog
MAGNETO ASSEMBLY 600 XCR 0941667 (4927092709040A)
5
Parts Diagram
Parts Catalog
OIL PUMP ASSEMBLY 600 XCR 0941667 (4927092709039A)
by
MAGNETO ASSEMBLY 600 XCR 0941667 (4927092709040A)
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1
STATOR PLATE ASM. (Incl. 1-4 6 7 14-21)
3084473
Not Available
1
MAGNETO CPL.
3084468
Not Available
2
COIL PULSE
3084511
Not Available
3
BAND
3084099
Not Available
4
SCREW & WASHER ASM.
3084096
Not Available
5
BOLT&WASHER ASM.
3083866
Not Available
6
STATOR Substituted by 3084473
3084509
Not Available
7
SCREW&WASHER
3084510
Not Available
8
FLYWHEEL ASM.
3084515
Not Available
9
CDI SYSTEM
3084472
Not Available
10
CAP SPARK PLUG (10)
4020129
4083595
$52,49 Unit Price incl. VAT
11
CODE CP
3084516
$35,69 Unit Price incl. VAT
12
COIL IGNITION
3085208
Not Available
13
ASM. BOLT AND WASHER
3083730
$9,44 Unit Price incl. VAT
14
COUPLER 2P
3084513
Not Available
15
COUPLER
3083909
$41,99 Unit Price incl. VAT
16
COUPLER MALE
3081513
$36,74 Unit Price incl. VAT
17
HARNESS WIRE
3084514
Not Available
18
GROMMET
3082969
Not Available
19
CLAMP
3081146
$2,09 Unit Price incl. VAT
20
SCREW&WASHER ASM(10)
3081256
$6,29 Unit Price incl. VAT
21
BAND WIRE
3084512
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
