1
Engine displacement
1200
2
Year
2002
3
Trim
GENESIS I - W025098D
4
Parts Catalog
ELECTRICAL
5
Parts Diagram
Parts Catalog
WATER SIPHON
by
BATTERY BOX
ELECTRICAL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
12
30
30
30
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
12
30
30
30
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
12
30
30
30
1
1
1
1
1
2
3
4
5
6
7
8
9
10
11
12
12
13
13
13
13
14
15
15
16
17
18
1
2
3
4
5
6
7
8
9
9
10
10
10
11
12
13
14
15
16
17
18
19
1
DECAL ELECT.BOX RESET
7073734
Not Available
2
CKT.BREAKER 15A.(WATER.)
2434011
$33,06 Unit Price incl. VAT
3
O-Ring
5412187
Not Available
4
Base
5433485
Not Available
5
RVT-3/16(.187-.375)AL-AL/BULBX
7621479
$3,66 Unit Price incl. VAT
6
Bracket Solenoid Reset
5245997
Not Available
7
Cut-Off Start/Stop
4010724
Not Available
8
FUSE (10)
4060111
$3,45 Unit Price incl. VAT
9
Fuse 3 Amp
4060161
Not Available
10
ANCHOR CABLE TIE(10)
7080464
$4,61 Unit Price incl. VAT
11
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
12
CONDUIT WIRE 2.5CM (2.5 cm)
55212862.5
$3,45 Unit Price incl. VAT
13
Solenoid Starter
4010858
Not Available
14
WASHER(10)
7555882
$3,35 Unit Price incl. VAT
15
WASHER LOCK(10)
7552613
Not Available
16
SCR-M6X1.0X12 PH/PAN HD-SS
7517717
$1,77 Unit Price incl. VAT
17
STRAP PANDUIT 4 IN.(10)
7080483
Not Available
18
NUT 6 MM. S.S.(10)
7546705
$9,44 Unit Price incl. VAT
19
Washer
7556218
$0,93 Unit Price incl. VAT
20
RIVET-POP (50)
7661042
$1,77 Unit Price incl. VAT
21
Cover Circuit Breaker
5433484
$56,90 Unit Price incl. VAT
22
SCR-M5X0.8X12 PH PN SS
7517897
Not Available
23
O-RING
5411491
$1,67 Unit Price incl. VAT
24
BOOT THREADED RED
7080461
$17,94 Unit Price incl. VAT
25
Cable Battery/Solenoid
4010641
$27,92 Unit Price incl. VAT
26
CABLE-SOLENOID/STARTER
4010237
Not Available
27
Harness RVS
2461001
$62,04 Unit Price incl. VAT
28
Harness Chassis
2461072
Not Available
29
CONDUIT WIRE 2.5CM (2.5 cm)
55212862.5
$3,45 Unit Price incl. VAT
30
Clip
7670148
Not Available
30
Screw
7518038
Not Available
30
Harness Engine
2460994
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
