Parts Catalog
BRAKE LIGHT 0953433, STARLITE 0953427 AND LITE DELUXE 0953431 (4928902890B006)
5
Parts Diagram
Parts Catalog
STEERING ASSEMBLY LITE 0953433, STARLITE 0953427 AND LITE DELUXE 0953431 (4928902890B004)
by
CHAINCASE ASSEMBLY LITE 0953433, STARLITE 0953427 AND LITE DELUXE 0953431 (4928902890B007)
BRAKE LIGHT 0953433, STARLITE 0953427 AND LITE DELUXE 0953431 (4928902890B006)
1
CLIP-EDGE 16MM
7080427
Not Available
2
BRKT BRAKE BLK.
5220211067
Not Available
3
WASHER
7555806
$1,56 Unit Price incl. VAT
4
WASHER SPRINGLOCK(10) Substituted by 7552603
7553001
7552603
$1,56 Unit Price incl. VAT
5
SCR-3/8-16X1.25 HX HD CP GR5-Y
7515440
$7,34 Unit Price incl. VAT
6
BRKT BRAKE TOP MT.
5240240067
$31,80 Unit Price incl. VAT
7
BUSHING
1930559
Not Available
8
NUT(10)
7542425
Not Available
9
SPACER ALIGNMENT
5020695
$4,61 Unit Price incl. VAT
10
CALIPER
5630305
$68,24 Unit Price incl. VAT
11
PUCK
1930592
Not Available
12
PAD BRAKE (THICK)
1930588
Not Available
13
CALIPER
1930593
Not Available
14
SPRING BRAKE RETURN
7041147
Not Available
15
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
16
BUSHING
5332795
Not Available
17
BOLT(10)
7512240
$7,34 Unit Price incl. VAT
18
PIN CLEVIS
7080316
Not Available
19
BOLT(10)
7515478
$19,94 Unit Price incl. VAT
20
DECAL BRAKE [No Longer Available] (SS)
7072088
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
