1
Engine displacement
800
2
Year
2014
3
Trim
SPORTSMAN 800 EFI 6X6 FOREST - A14CF76FA
4
Parts Catalog
WIRE HARNESSES
5
Parts Diagram
Parts Catalog
BATTERY
by
HEADLIGHTS
WIRE HARNESSES
1
2
3
3
3
3
3
3
4
5
6
7
8
9
10
11
12
12
13
14
14
1
Harness Main 6X6 [Incl. 1-3 6-9 12-14 All Kits]
2411621
Not Available
2
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
3
KIT FUSIBLE LINK 1.0 MM
2202670
$68,24 Unit Price incl. VAT
3
KIT FUSIBLE LINK .8 MM
2202607
$73,49 Unit Price incl. VAT
3
Kit Harness CPS
2878077
$220,49 Unit Price incl. VAT
3
KIT HARNESS T-BAP
2875542
2878494
$220,49 Unit Price incl. VAT
3
KIT HARNESS ENGINE TEMP
2875543
$209,99 Unit Price incl. VAT
3
Kit Harness TPS
2203801
$220,49 Unit Price incl. VAT
4
Harness Winch [Built 4/03/12 and After]
2412244
$204,74 Unit Price incl. VAT
5
Relay
4011141
$141,74 Unit Price incl. VAT
6
COVER - DIAGNOSTIC W/ CLIP
4012170
4083556
$15,00 Unit Price incl. VAT
7
FUSE 20 AMP
4011683
$18,89 Unit Price incl. VAT
8
FUSE 15 AMP
4011682
$15,74 Unit Price incl. VAT
9
Fuse 5 Amp
4011681
$15,74 Unit Price incl. VAT
10
SCR-#10-24X1/2PH/TORX-TRIRD-Y
7512024
$9,44 Unit Price incl. VAT
11
Bracket Fuse Block
5250236
$12,59 Unit Price incl. VAT
12
BREAKER-CIRCUIT 20 AMP SEALED
2410881
$141,74 Unit Price incl. VAT
13
Decal Fuse Block
7171032
Not Available
14
CAPACITOR FILTER
4011441
$194,24 Unit Price incl. VAT

Find the detailed WIRE HARNESSES POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
