1
Engine displacement
0
2
Year
2016
3
Trim
GEM (R20) - L16G2/4/6/EURO ALL OPTIONS
4
Parts Catalog
BODY, TRIM, REAR
5
Parts Diagram
Parts Catalog
TOOL BOX
by
WINDSHIELD, WIPER, LH
BODY, TRIM, REAR
1
2
18
4
4
5
5
6
7
8
9
10
11
12
13
14
14
15
15
16
16
17
18
18
19
20
21
22
23
24
24
25
25
26
27
28
29
30
31
32
1
WELD-SUPPORT BED REAR BLK
1021674458
Not Available
2
WELD-SIDE BED LH
1021734
Not Available
3
SCR-HXBH-M8X1.25X25 A2 SS
7520126
Not Available
4
NUT- M8X1.25 FLG NYLOC-OLIVE D
7547332
$7,34 Unit Price incl. VAT
5
WASHER
7555954
$9,44 Unit Price incl. VAT
6
WELD-SIDE BED RH
1021735
Not Available
7
BRKT-MOUNT TAILLIGHT
5261455
Not Available
8
COVER-BATTERY
5261458
Not Available
9
BRKT-FENDER BRACE
5262120
Not Available
10
BRKT-BED STIFFNER LH
5262338
Not Available
11
BRKT-BED STIFFNER RH
5262339
Not Available
12
LINER-FLOOR REAR BLK
5452113070
Not Available
13
PLUG-RECTANGULAR TUBING
5452653
Not Available
14
SCR-M8X1.25X30 SOC/FLT/HD-SS
7518250
$2,82 Unit Price incl. VAT
15
BOLT-M8X1.25X25 HXFLG-OLIVE D
7518514
$3,14 Unit Price incl. VAT
16
SCR-HXFL-M6X1.0X20 8.8 ZOD NYL
7518613
$7,34 Unit Price incl. VAT
17
BOLT-M6X1.0X20 PH/TX-OLIVE D
7518616
$2,09 Unit Price incl. VAT
18
SCR-HXBH-M8X1.25X25 A2 SS
7520126
Not Available
19
SCR-TXTH-M8X1.25X25 8.8 ZODP30
7519070
$11,54 Unit Price incl. VAT
20
SCR-HXFL-M10X1.25X80 8.8 ZOD
7519363
7528444
$4,19 Unit Price incl. VAT
21
WASHER
7556153
$3,66 Unit Price incl. VAT
22
NUT-M10X1.25 FLG NYLOC-OLIVE D
7547333
$3,14 Unit Price incl. VAT
23
NUT-M6X1.0 FLG-NYLOC-OLIVE D
7547339
$2,09 Unit Price incl. VAT
24
NUT-RIVNUT M8X1.25
7547788
Not Available
25
NUT-RIVNUT M6X1.00
7547789
$6,29 Unit Price incl. VAT
26
RIVET-TUFLOK .315-.325X.787 ?
7661855
$2,09 Unit Price incl. VAT
27
PANEL-BACK WHITE
5452514599
Not Available
28
PANEL-REAR LH WHITE
5452515599
Not Available
29
PANEL-REAR RH WHITE
5452516599
Not Available
30
BRKT-SUPPORT BED SHORT
5261397
Not Available
31
BRKT-SUPPORT BED LONG
5261398
Not Available
32
PLUG - REVERSE LAMP
5452866
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
