Parts Diagram

HOOD

BRAKE LIGHT/0933433,STARLITE/0933427 AND LITE DELUXE/0933431 (4922972297013A) FOR LITE - 0933433 FROM 1993

CHAINCASE ASSEMBLY LITE/0933433,STARLITE/0933427 AND LITE DELUXE/0933431 (4922972297014A)

Part numbers

CLIP-EDGE 16MM

7080427

Not Available

BRKT BRAKE BLK.

5220211067

Not Available

BRKT BRAKE MTG.

5220514067

Not Available

BOLT(10)

7512240

$7,34 Unit Price incl. VAT

WASHER SPRING LOCK

7552801

$3,14 Unit Price incl. VAT

BUSHING

1930559

Not Available

NUT(10)

7542425

Not Available

CALIPER

5630305

$68,24 Unit Price incl. VAT

PUCK

1930592

Not Available

PAD BRAKE (THICK)

1930588

Not Available

CALIPER

1930593

Not Available

SPRING BRAKE RETURN

7041147

Not Available

NUT NYLOK

7542122

$2,09 Unit Price incl. VAT

BUSHING

5332795

Not Available

PIN CLEVIS

7080316

Not Available

BOLT(10)

7515478

$19,94 Unit Price incl. VAT

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
