1
Engine displacement
0
2
Year
1992
3
Trim
lite-0923033
4
Parts Catalog
STEERING INDY LITE/STAR LITE (4921332133011A)
5
Parts Diagram
Parts Catalog
FRONT SUSPENSION AND SKI INDY LITE/STAR LITE (4921332133009A)
by
SUSPENSION INDY LITE/STAR LITE (4921332133013A)
STEERING INDY LITE/STAR LITE (4921332133011A)
1
1
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
13
13
13
13
13
13
14
14
15
15
16
16
16
16
17
17
18
18
18
18
19
19
20
20
21
21
22
22
23
23
23
23
24
24
24
24
25
25
26
26
27
27
27
27
27
27
27
27
28
28
29
29
30
30
31
31
32
32
33
33
34
34
35
35
36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
37
37
38
38
38
38
38
38
38
38
38
38
38
38
38
38
38
38
39
39
39
39
39
39
39
39
39
39
39
39
39
39
39
39
40
40
41
41
42
42
43
43
44
44
44
44
45
45
45
45
46
46
46
46
47
47
48
48
48
48
49
49
49
49
50
50
51
51
52
52
53
53
54
54
56
56
56
56
57
57
58
58
59
59
60
60
61
61
62
62
63
63
64
64
65
65
66
66
68
68
68
68
68
68
68
68
68
68
68
68
68
68
68
1
1
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
13
13
13
13
13
13
14
14
15
15
16
16
16
16
17
17
18
18
18
18
19
19
20
20
21
21
22
22
23
23
23
23
24
24
24
24
25
25
26
26
27
27
27
27
27
27
27
27
28
28
29
29
30
30
31
31
32
32
33
33
34
34
35
35
36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
37
37
38
38
38
38
38
38
38
38
38
38
38
38
38
38
38
38
39
39
39
39
39
39
39
39
39
39
39
39
39
39
39
39
40
40
41
41
42
42
43
43
44
44
44
44
45
45
45
45
46
46
46
46
47
47
48
48
48
48
49
49
49
49
50
50
51
51
52
52
53
53
54
54
56
56
56
56
57
57
58
58
59
59
60
60
61
61
62
62
63
63
64
64
65
65
66
66
68
68
68
68
68
68
68
68
68
68
68
68
68
68
68
1
1
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
13
13
13
13
13
13
14
14
15
15
16
16
16
16
17
17
18
18
18
18
19
19
20
20
21
21
22
22
23
23
23
23
24
24
24
24
25
25
26
26
27
27
27
27
27
27
27
27
28
28
29
29
30
30
31
31
32
32
33
33
34
34
35
35
36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
37
37
38
38
38
38
38
38
38
38
38
38
38
38
38
38
38
38
39
39
39
39
39
39
39
39
39
39
39
39
39
39
39
39
40
40
41
41
42
42
43
43
44
44
44
44
45
45
45
45
46
46
46
46
47
47
48
48
48
48
49
49
49
49
50
50
51
51
52
52
53
53
54
54
56
56
56
56
57
57
58
58
59
59
60
60
61
61
62
62
63
63
64
64
65
65
66
66
68
68
68
68
68
68
68
68
68
68
68
68
68
68
68
1
1
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
13
13
13
13
13
13
14
14
15
15
16
16
16
16
17
17
18
18
18
18
19
19
20
20
21
21
22
22
23
23
23
23
24
24
24
24
25
25
26
26
27
27
27
27
27
27
27
27
28
28
29
29
30
30
31
31
32
32
33
33
34
34
35
35
36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
37
37
38
38
38
38
38
38
38
38
38
38
38
38
38
38
38
38
39
39
39
39
39
39
39
39
39
39
39
39
39
39
39
39
40
40
41
41
42
42
43
43
44
44
44
44
45
45
45
45
46
46
46
46
47
47
48
48
48
48
49
49
49
49
50
50
51
51
52
52
53
53
54
54
56
56
56
56
57
57
58
58
59
59
60
60
61
61
62
62
63
63
64
64
65
65
66
66
68
68
68
68
68
68
68
68
68
68
68
68
68
68
68
1
1
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
13
13
13
13
13
13
14
14
15
15
16
16
16
16
17
17
18
18
18
18
19
19
20
20
21
21
22
22
23
23
23
23
24
24
24
24
25
25
26
26
27
27
27
27
27
27
27
27
28
28
29
29
30
30
31
31
32
32
33
33
34
34
35
35
36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
37
37
38
38
38
38
38
38
38
38
38
38
38
38
38
38
38
38
39
39
39
39
39
39
39
39
39
39
39
39
39
39
39
39
40
40
41
41
42
42
43
43
44
44
44
44
45
45
45
45
46
46
46
46
47
47
48
48
48
48
49
49
49
49
50
50
51
51
52
52
53
53
54
54
56
56
56
56
57
57
58
58
59
59
60
60
61
61
62
62
63
63
64
64
65
65
66
66
68
68
68
68
68
68
68
68
68
68
68
68
68
68
68
1
GRIP H#BAR BLACK Substituted by 5432634
5410272067
$52,49 Unit Price incl. VAT
1
HEATER GRIP ASM.
2460313
Not Available
2
HANDLEBAR ADJ BLK.
1843036067
Not Available
3
BLOCK THROTTLE/BRAKE Substituted by 5431592
5431265
5431592
$73,49 Unit Price incl. VAT
4
LEVER-BRAKE
5430602
$68,24 Unit Price incl. VAT
5
SWITCH DIMMER
4110104
Not Available
6
SWITCH BRAKE LIGHT
4110105
Not Available
7
PIN RETAINING
7661624
$23,09 Unit Price incl. VAT
8
WASHER
7555730
$7,34 Unit Price incl. VAT
9
RING RETAINING
7710401
$7,34 Unit Price incl. VAT
10
SWITCH AUX.SHUT-OFF
4110106
$141,74 Unit Price incl. VAT
11
ADAPTOR BLOCK
5430604
$26,24 Unit Price incl. VAT
12
LEVER-THROTTLE
5430601
Not Available
13
COVER H#BAR(W/O SPEEDO) (WO/Speedometer)
5431233070
Not Available
13
COVER H#BAR W/SPEEDO (W/Speedometer)
5431232070
Not Available
14
SCR-#10-24X1/2PH/TORX-TRIRD-Y
7512024
$9,44 Unit Price incl. VAT
15
BOOT STRG.POST
5431234070
Not Available
16
SCR-6X3/8 PH TR HD GR5-Y
7511848
$7,34 Unit Price incl. VAT
17
BLOCK HANDLEBAR BLACK
5630187067
$73,49 Unit Price incl. VAT
18
SCR-SHSEMS-3/8-16X0.375 GR8 Z
7512465
$7,34 Unit Price incl. VAT
19
BRKT UP.STRG.BUSH BLK. Substituted by 5222999-067
5220887067
5257028
$62,99 Unit Price incl. VAT
20
BUSHING STRG. UPPER Substituted by 5431572
5430966
5433416
$16,79 Unit Price incl. VAT
21
BUSHING UPPER STRG. Substituted by 5431573
5431138
5433415
$16,79 Unit Price incl. VAT
22
BOLT(10)
7515321
Not Available
23
WASHER-.344X.688X.063 FL-Y
7558402
$1,56 Unit Price incl. VAT
24
NUT-5/16-18 NYLOK-Y [INTL]
7542324
$1,56 Unit Price incl. VAT
25
BOLT (10)
7512265
$7,34 Unit Price incl. VAT
26
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
27
POST STEERING BLK. [No Longer Available] (Star)
1823149067
Not Available
27
POST STRG BLK. (Indy)
1823150067
Not Available
28
SPEEDOMETER (Indy Lite)
3280112
Not Available
29
SPACER
5410592
Not Available
30
SPACER SPEEDO.MTG. (Indy Lite)
5810442
Not Available
31
PLATE MTG (SPEEDO) (Indy Lite)
5211189
$19,94 Unit Price incl. VAT
32
WASHER FLAT
7558201
$9,44 Unit Price incl. VAT
33
HAIRPIN COTTER(10) (Indy Lite)
7660701
$3,66 Unit Price incl. VAT
34
BRKT BOLT RETAINER
5222421
Not Available
35
BOLT(10) Substituted by 7512377
7512394
7512377
$9,44 Unit Price incl. VAT
36
FROG LH STRG. (Indy Lite)
5222402
Not Available
36
FROG RH STRG. (Star Lite)
5222403
Not Available
37
ROD DRAG LINK
5333005
Not Available
38
ROD END RH Substituted by 7060165
7060125
7060165
$99,74 Unit Price incl. VAT
38
ROD END LH Substituted by 7060166
7060151
7060166
$99,74 Unit Price incl. VAT
39
NUT-3/8-24-(L.H.)-Y
7542424
$1,56 Unit Price incl. VAT
39
NUT-3/8-24-2B-Z
7542401
$4,19 Unit Price incl. VAT
40
ROD TIE BLK.
5333006067
Not Available
41
ROD END LH Substituted by 7060164
7060124
7060164
$99,74 Unit Price incl. VAT
42
O RING
5410591
Not Available
43
BOOT TIE ROD Substituted by 5411652
5410639
Not Available
44
RETAINER BOOT
5222283
Not Available
45
SCR-HH-3/8-24X5.5 GR5 ZY3
7512404
$7,34 Unit Price incl. VAT
46
NUT FLEXLOC(10) Substituted by 7542411
7542452
7542411
$6,29 Unit Price incl. VAT
47
BUSHING SPACER
5333009
$19,20 Unit Price incl. VAT
48
BUSHING
5630371
$8,07 Unit Price incl. VAT
49
WASHER(10)
7555817
Not Available
50
BOLT(10)
7512572
$23,09 Unit Price incl. VAT
51
NUT FLANGE
7542423
$7,34 Unit Price incl. VAT
52
PIN COTTER
7661203
$2,09 Unit Price incl. VAT
53
HOOP STRG BLK.
1011782067
Not Available
54
BOLT CARRIAGE
7512298
$7,34 Unit Price incl. VAT
56
CABLE-TIE DIA12-50MM WTHR-RES.
7080138
$5,24 Unit Price incl. VAT
57
Nut
7542403
Not Available
58
CLIP (10)
5222672
Not Available
59
BLOCK H#BAR UPPER BLK.
5630382067
Not Available
60
RINGMOUNT RECOIL BLK.
5224442067
$34,32 Unit Price incl. VAT
61
WASHER-.312 X .734 X .065-Z
7558302
$3,14 Unit Price incl. VAT
62
SCR-RHCAR-1/4-20X0.75 GR5 ZY3
7512193
$4,19 Unit Price incl. VAT
63
RIVET
7661617
$7,34 Unit Price incl. VAT
64
CLIP-SPEED.(10)
7670044
$9,44 Unit Price incl. VAT
65
CLIP STRG.BOOT(10)
7670073
Not Available
66
SCREW(10)
7515434
Not Available
68
BURR RIVET(50) Substituted by 7555904
7555746
7555904
$1,56 Unit Price incl. VAT
68
DRIVE ANGLE (STARLITE)
3280114
Not Available
68
CABLE SPEEDOMETER
3280113
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.

Other Parts for LITE - 0923033

CHASSIS AND SEAT INDY LITE/STAR LITE (4921332133001A)

CHASSIS AND SEAT INDY LITE/STAR LITE (4921332133001A)

for LITE - 0923033 from 1992

NOSEPAN CONSOLE INDY LITE/STAR LITE (4921332133003A)

NOSEPAN CONSOLE INDY LITE/STAR LITE (4921332133003A)

for LITE - 0923033 from 1992

HOOD ASSEMBLY INDY LITE/STAR LITE (4921332133005A)

HOOD ASSEMBLY INDY LITE/STAR LITE (4921332133005A)

for LITE - 0923033 from 1992

HOOD

HOOD

for LITE - 0923033 from 1992

FRONT/REAR TORQUE ARM INDY LITE/STAR LITE (4921332133015A)

FRONT/REAR TORQUE ARM INDY LITE/STAR LITE (4921332133015A)

for LITE - 0923033 from 1992

DRIVE CLUTCH INDY LITE/STAR LITE (4921332133017A)

DRIVE CLUTCH INDY LITE/STAR LITE (4921332133017A)

for LITE - 0923033 from 1992

DRIVEN CLUTCH INDY LITE/STAR LITE (4921332133018A)

DRIVEN CLUTCH INDY LITE/STAR LITE (4921332133018A)

for LITE - 0923033 from 1992

ENGINE MOUNTING INDY LITE (4921332133019A)

ENGINE MOUNTING INDY LITE (4921332133019A)

for LITE - 0923033 from 1992

CYLINDER INDY LITE (4921332133027A)

CYLINDER INDY LITE (4921332133027A)

for LITE - 0923033 from 1992

PISTON CRANKSHAFT INDY LITE (4921332133028A)

PISTON CRANKSHAFT INDY LITE (4921332133028A)

for LITE - 0923033 from 1992

PISTON CRANKSHAFT STAR LITE (4921332133029A)

PISTON CRANKSHAFT STAR LITE (4921332133029A)

for LITE - 0923033 from 1992

BLOWER HOUSING/RECOIL STARTER INDY LITE (4921332133030A)

BLOWER HOUSING/RECOIL STARTER INDY LITE (4921332133030A)

for LITE - 0923033 from 1992

MAGNETO INDY LITE (4921332133035A)

MAGNETO INDY LITE (4921332133035A)

for LITE - 0923033 from 1992

MAGNETO STAR LITE (4921332133036A)

MAGNETO STAR LITE (4921332133036A)

for LITE - 0923033 from 1992

CARBURETOR INDY LITE (4921332133037A)

CARBURETOR INDY LITE (4921332133037A)

for LITE - 0923033 from 1992

CARBURETOR STAR LITE (4921332133038A)

CARBURETOR STAR LITE (4921332133038A)

for LITE - 0923033 from 1992

RECOIL STARTER STAR LITE (4921332133039A)

RECOIL STARTER STAR LITE (4921332133039A)

for LITE - 0923033 from 1992

HOOD

HOOD

for LITE - 0923033 from 1992

FRONT SUSPENSION AND SKI INDY LITE/STAR LITE (4921332133009A)

FRONT SUSPENSION AND SKI INDY LITE/STAR LITE (4921332133009A)

for LITE - 0923033 from 1992

STEERING INDY LITE/STAR LITE (4921332133011A)

STEERING INDY LITE/STAR LITE (4921332133011A)

for LITE - 0923033 from 1992

SUSPENSION INDY LITE/STAR LITE (4921332133013A)

SUSPENSION INDY LITE/STAR LITE (4921332133013A)

for LITE - 0923033 from 1992

ENGINE MOUNTING STAR LITE (4921332133021A)

ENGINE MOUNTING STAR LITE (4921332133021A)

for LITE - 0923033 from 1992

HOOD _ FOAM/FOIL INDY LITE/STAR LITE (4921332133023A)

HOOD _ FOAM/FOIL INDY LITE/STAR LITE (4921332133023A)

for LITE - 0923033 from 1992

CRANKCASE INDY LITE (4921332133025A)

CRANKCASE INDY LITE (4921332133025A)

for LITE - 0923033 from 1992

CRANKCASE AND CYLINDER STAR LITE (4921332133026A)

CRANKCASE AND CYLINDER STAR LITE (4921332133026A)

for LITE - 0923033 from 1992

BLOWER HOUSING STAR LITE (4921332133031A)

BLOWER HOUSING STAR LITE (4921332133031A)

for LITE - 0923033 from 1992

FUEL PUMP INDY LITE/STAR LITE (4921332133032A)

FUEL PUMP INDY LITE/STAR LITE (4921332133032A)

for LITE - 0923033 from 1992

OIL PUMP INDY LITE (4921332133033A)

OIL PUMP INDY LITE (4921332133033A)

for LITE - 0923033 from 1992

OIL PUMP STAR LITE (4921332133034A)

OIL PUMP STAR LITE (4921332133034A)

for LITE - 0923033 from 1992

BRAKE INDY LITE/STAR LITE (4921332133040A)

BRAKE INDY LITE/STAR LITE (4921332133040A)

for LITE - 0923033 from 1992

DRIVE TRAIN INDY LITE/STAR LITE (4921332133041A)

DRIVE TRAIN INDY LITE/STAR LITE (4921332133041A)

for LITE - 0923033 from 1992

POLARIS LITE - 0923033 1992

LITE - 0923033

LITE - 0923033

Model : OTHERS

Year : 1992

New and OEM parts
International Shipping
Official price POLARIS
A team of experts at your service
Secure Payment
By your side since 2001
Customer Reviews
4.2 /5
1764 Reviews
View all reviews
Spare parts catalogue for all brands
