1
Engine displacement
1000
2
Year
2018
3
Trim
RZR XP 4 1000 MD
4
Parts Catalog
POWER STEERING
5
Parts Diagram
Parts Catalog
CRANKCASE AND CRANKSHAFT
by
FRONT SUSPENSION CARRIER- Z18VFE99NK (702255)
POWER STEERING
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
17
18
19
19
20
21
21
22
23
24
25
26
27
28
29
1
ASM. GEAR BOX STEERING [INCL. 2-7]
1824469
1824835
$1 049,99 Unit Price incl. VAT
2
BOOT DRIVERS SIDE RACK
5412012
$115,49 Unit Price incl. VAT
3
BOOT PASSENGER SIDE RACK
5412013
$104,99 Unit Price incl. VAT
4
TIE ROD OUTER
7061234
$89,24 Unit Price incl. VAT
5
NUT JAM LH THREAD
2205058
$41,99 Unit Price incl. VAT
6
BELLOWS CLAMP SMALL
7082150
$12,59 Unit Price incl. VAT
7
CLAMP LARGE BELLOWS
7080979
$10,49 Unit Price incl. VAT
8
ASM-TILT STEERING RVTD M10 BLK [INCL.10]
1824420458
$283,49 Unit Price incl. VAT
9
SHAFT STEERING UPPER
1823891
$272,99 Unit Price incl. VAT
10
SHAFT STEERING LOWER W/JOINTS
1824012
$257,24 Unit Price incl. VAT
11
ASM-POWER STEERING RZR XP
2413483
$3 344,24 Unit Price incl. VAT
12
MOUNT EPS BLACK
5257531329
$225,74 Unit Price incl. VAT
13
NUT-6MM X 1 NYLOK-Z
7546703
$2,09 Unit Price incl. VAT
14
NUT-M12X1.5 FLG NYLOC-OLIVE D
7547334
$9,44 Unit Price incl. VAT
15
BOLT-M10X1.25X20 HXFLG-OLV D
7518558
$7,34 Unit Price incl. VAT
16
SCR-M10X1.50X35 HX/FL
7518644
$9,44 Unit Price incl. VAT
17
SCR-HXFL-M8X1.25X35 8.8 ZOD
7519052
$3,14 Unit Price incl. VAT
18
NUT-M10X1.25 FLG NYLOC-OLIVE D
7547333
$3,14 Unit Price incl. VAT
19
NUT- M8X1.25 FLG NYLOC-OLIVE D
7547332
$7,34 Unit Price incl. VAT
20
NUT-NY INS M10X1.5 HEX ZINC YW
7547385
$2,09 Unit Price incl. VAT
21
BUSHING-STEERING
7556675
$24,14 Unit Price incl. VAT
22
WHEEL STEERING [TO 2/1/2023]
1824014
2209704
$248,84 Unit Price incl. VAT
23
CAP STEERING WHEEL I. RED [TO 2/1/2023]
5450255293
$52,49 Unit Price incl. VAT
24
BOLT-M10X1.25X130 HXFLG-OLIVED
7518665
$25,19 Unit Price incl. VAT
25
NUT-HEX-M16X2 8 ZC NYL
7547506
$7,34 Unit Price incl. VAT
26
ASM-SHOCK OIL LOCKING MACH
7044098
$178,49 Unit Price incl. VAT
27
SCR-SH-M6X1.0X11 12.9 ZB SHB
7519980
$13,64 Unit Price incl. VAT
28
COVER EPS
5438626
$68,24 Unit Price incl. VAT
29
SCR-TXTH-M6X1.0X15 ZPB TAP
7519092
$2,09 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
