FRONT SUSPENSION AND SKI TRAIL (4919281928009A) FOR SWE TRAIL DELUXE

CHASSIS AND SEAT TRAIL (4919281928001A)

STEERING TRAIL (4919281928011A)

BOLT(10)

7512551

Not Available

BOLT(10)

7512656

$11,01 Unit Price incl. VAT

Nut

7542403

Not Available

SCREW

7515415

$2,09 Unit Price incl. VAT

RETAINER SPRING COIL

5220225

$19,94 Unit Price incl. VAT

SPRING BLACK Substituted by 7041261-067

7041242067

7041261-067

$246,74 Unit Price incl. VAT

RETAINER-SPRING

5210953

$11,54 Unit Price incl. VAT

SHOCK FR.SUSP. (400 600)

7041144

Not Available

PIN-3/32X3/4-COTTER-Y

7661205

$1,56 Unit Price incl. VAT

SCR-HH-3/8-24X5.5 GR5 ZY3

7512404

$7,34 Unit Price incl. VAT

NUT-3/8-24 HX CA GR5-Y

7542438

$3,14 Unit Price incl. VAT

SLIDE-SWAYBAR

5410384

Not Available

BOLT Substituted by 7515491

7515433

$3,14 Unit Price incl. VAT

WASHER

7555721

$2,09 Unit Price incl. VAT

TUBE TRAILING ARM

5010187

Not Available

PIVOT-TRAILING ARM

5410382

Not Available

BOLT(10)

7512557

$11,54 Unit Price incl. VAT

ARM-TRAILING RH Substituted by 1822052-067

1822052

Not Available

ARM-TRAILING LH Substituted by 1822053-067

1822053

Not Available

STOP STRNG RH BLK. Substituted by 5220238-067

5220238

Not Available

STOP STRNG LH BLK. Substituted by 5220237-067

5220237

Not Available

ARM STEERING Substituted by 5220326-067

5220326

Not Available

WASHER(10) Substituted by 7555806

7555720

7555806

$1,56 Unit Price incl. VAT

BUSHING FLANGED

3574208

$6,29 Unit Price incl. VAT

RIVET

7621433

$2,09 Unit Price incl. VAT

SPINDLE GREASABLE Substituted by 5130919-067

6230055

Not Available

FITTING-LUBE.(10) Substituted by 7080561

7080220

$9,44 Unit Price incl. VAT

BUSHING [BEA]

5010158

$27,29 Unit Price incl. VAT

STOP-RUBBER

5521094

Not Available

NUT-5/16-18 NYLOK-Y [INTL]

7542324

$1,56 Unit Price incl. VAT

BOLT(10)

7515462

$15,74 Unit Price incl. VAT

SKAG SHORT(20) (Sport)

1820267

$40,94 Unit Price incl. VAT

SKAG CARBIDE TRAIL E/S Substituted by 2870693 (650 SKS Only)

1820266

$99,74 Unit Price incl. VAT

SKI Substituted by 1820332-067 (Trail Trail ES Only)

1820268

Not Available

SKI Substituted by 1820332-067 (Trail Special & Deluxe Only)

1820264

Not Available

BOLT(10) Substituted by 7515492

7512410

7515540

$9,44 Unit Price incl. VAT

BUSHING

5010127

$12,59 Unit Price incl. VAT

ROD RADIUS Substituted by 1822045-067

182204501

Not Available

ROD RADIUS Substituted by 1822037-067

182203701

Not Available

NUT JAM(10)

7542520

$4,19 Unit Price incl. VAT

ROD END RH

7060126

Not Available

STRAP-SPACER

5220178

$2,19 Unit Price incl. VAT

NUT LOCK (10)

7542503

$18,89 Unit Price incl. VAT

BRACE PAN Substituted by 5223997-067

5223997

Not Available

NUT FLEX (10)

7542703

Not Available

ROD END

7060127

Not Available

STRAP-SPACER BOTTOM

5220227

Not Available

NUT-1/2-20 HX JM-Y

7542711

$4,19 Unit Price incl. VAT

NUT FLEXLOC

7542411

$6,29 Unit Price incl. VAT

BUSHING FLANGE

3573909

$4,19 Unit Price incl. VAT

BUSHING

7556509

$3,14 Unit Price incl. VAT

BAR SWAY BLACK

5224237067

Not Available

BUSHING-SWAYBAR

5410383

Not Available

DECAL RH IFS RED [No Longer Available]

7072951

Not Available

DECAL LH IFS RED [No Longer Available]

7072950

Not Available

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
