CYLINDER MANIFOLD FOR SLTH - B994573 FROM 1999

CYLINDER MANIFOLD

-

KIT GASKET SET COMP.

2200680

$115,49 Unit Price incl. VAT

-

KIT GASKET TOP END

2200673

Not Available

1

DECAL WARNING

7075383

Not Available

2

BOLT(10)

7516806

Not Available

3

GASKET WATER MANIF.

5830061

Not Available

4

BOLT(10)

7516722

$15,42 Unit Price incl. VAT

5

SCREW (10) Substituted by 7517352

7517251

Not Available

6

O-RING-3.489X3.629X.07 HI-TMP

5410932

$36,74 Unit Price incl. VAT

7

O-RING

5410931

$11,54 Unit Price incl. VAT

8

NUT

7547021

Not Available

9

CYLINDER 81MM PWC HP.

3021018

$704,54 Unit Price incl. VAT

10

GASKET CARB.

5830043

Not Available

11

BOLT(10)

7516814

$3,87 Unit Price incl. VAT

12

RETAINER SS.

7080654

$29,39 Unit Price incl. VAT

13

BOLT(10)

7516807

Not Available

14

MANIFOLD INTAKE

5630529

Not Available

15

STUFFER REED 75.5MM(34MMCARB)

5432681

Not Available

16

REEDVALVE ASM. Substituted by 1201743

1201689

Not Available

17

GASKET CYL.BASE

5830123

$13,64 Unit Price incl. VAT

18

HEAD CYL 81MM PWC

3022050

$43,56 Unit Price incl. VAT

19

RING HEAD 81MM-SS

5241944

$85,88 Unit Price incl. VAT

20

O-RING(10)

5410917

$1,56 Unit Price incl. VAT

21

BRKT HEAD TWIN FIRE RED

5241768093

Not Available

22

COVER HEAD RED BIG BORE

5630527093

Not Available

23

SPARKPLUG BPR-8ES(10)

3070174

Not Available

24

SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]

*******

Not Available

25

MANIFOLD OUT FIRE RED Substituted by 1202061-093

5630826093

Not Available

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
