1
Engine displacement
570
2
Year
2016
3
Trim
ranger-570-full-size
4
Parts Catalog
BED BOX
5
Parts Diagram
Parts Catalog
STABILIZER BAR
by
DECALS
BED BOX
1
2
3
3
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
ASM. BOX SHORT BLACK [INCL. ALL]
2636007070
$1 574,99 Unit Price incl. VAT
2
WELD-TAILGATE SUPPORT LH BLK
1021456067
$89,24 Unit Price incl. VAT
3
SCR-TXPH-#14 X .75 HI-LO RIE
7519731
$7,34 Unit Price incl. VAT
4
BOX SHORT BLACK
5439087070
2207591
$1 333,49 Unit Price incl. VAT
5
PANEL BOX SHORT LH BLACK
5439111070
$314,99 Unit Price incl. VAT
6
BUMPER RUBBER 13.50 DIA X4.3 THK
5414486
$5,24 Unit Price incl. VAT
7
LATCH-SLAM TAILGATE
7081568
$62,99 Unit Price incl. VAT
8
NUT-M6 FLANGE NYLOC
7547274
$2,09 Unit Price incl. VAT
9
SCR-TXTH-M6X1.0X25 RIE SHDR
7519942
$9,44 Unit Price incl. VAT
10
SCR-TX TRUSS-#14X3/4 HI/LO ZBK
7519045
$6,29 Unit Price incl. VAT
11
WELD-TAILGATE SUPPORT RH BLK
1021458067
$104,99 Unit Price incl. VAT
12
SHIELD-HEAT BOX 3P FS
5261664
$62,99 Unit Price incl. VAT
13
SCR-#14X3/4 HI/LO-PH-PN TRX-M
7519205
$3,14 Unit Price incl. VAT
14
SHIELD-HEAT FOIL BOX RGR
5814456
$104,99 Unit Price incl. VAT
15
PANEL-BOX SHORT RH BLK
5439112070
$314,99 Unit Price incl. VAT
16
SHIELD-HEAT MUFFLER 3P FS
5814347
$62,99 Unit Price incl. VAT
17
BRKT-BOX TIE DOWN
5255204
$16,79 Unit Price incl. VAT
18
WASHER-.28 X .81 X .06 ST-M
7555935
$4,19 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
