1
Engine displacement
1000
2
Year
2017
3
Trim
RANGER CREW XP 1000 EPS ALL OPTIONS
4
Parts Catalog
ENGINE, COOLING SYSTEM
5
Parts Diagram
Parts Catalog
ELECTRICAL, IGNITION
by
COOLING, WATERPUMP
ENGINE, COOLING SYSTEM
15
15
15
15
15
15
16
16
17
18
19
19
20
21
22
22
23
24
25
25
26
27
27
28
29
30
31
32
1
MOUNT RADIATOR LH BLACK
5256596329
$89,24 Unit Price incl. VAT
2
ASM-RADIATOR [INCL. 2-5]
1240663
$1 244,24 Unit Price incl. VAT
3
ASM-RADIATOR CORE
1240664
$876,74 Unit Price incl. VAT
4
CAP
1240694
$73,49 Unit Price incl. VAT
5
FAN-ASSEMBLY
2411816
$645,74 Unit Price incl. VAT
6
BOLT M6X15MM
7519585
$17,84 Unit Price incl. VAT
7
GROMMET-FLANGED .36X.56X1.06
7052028
$11,54 Unit Price incl. VAT
8
SCR-M6X1.0X20 HXHD FLG TDFM BK
7518529
$2,09 Unit Price incl. VAT
9
HOSE [BULK SVC]
84500031525
$136,49 Unit Price incl. VAT
10
TUBE-COOLANT 1#
5141639
$83,99 Unit Price incl. VAT
10
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
11
HOSE UPPER RADIATOR
5414289
$167,99 Unit Price incl. VAT
12
HOSE LOWER RADIATOR
5414290
$83,99 Unit Price incl. VAT
13
HOSE ENGINE IN
5414291
$83,99 Unit Price incl. VAT
14
HOSE ENGINE OUT
5414292
$141,74 Unit Price incl. VAT
15
SPRINGBAND-CLAMP 35/12 BLK
7080844
$19,94 Unit Price incl. VAT
16
CLAMP-HOSE(WORM DR)25-40MM
7081192
$14,69 Unit Price incl. VAT
17
SCR-M6X1.0X20 HXHD FLG TDFM BK
7518529
$2,09 Unit Price incl. VAT
18
CLIP-SILENCER BOX-C 98 INDY
7670102
$4,19 Unit Price incl. VAT
19
CAP-OVER FLOW BOTTLE DRILLED
5430743
$10,49 Unit Price incl. VAT
19
CAP OVER FLOW BOTTLE W/FITTING
5437635
$9,44 Unit Price incl. VAT
20
PLUG-CAP 9X(GREEN) FLEX TEMP
5433774
$10,49 Unit Price incl. VAT
21
GASKET-OVERFLOW CAP
5810279
$4,19 Unit Price incl. VAT
22
SCR-#14X1 HI/LO-PH-PN TRX-M
7518158
$9,44 Unit Price incl. VAT
23
SHROUD-RADIATOR FRONT BLK
5454760070
$115,49 Unit Price incl. VAT
24
RIVET-TUFLOK .315-.325X.787 ?
7661855
$2,09 Unit Price incl. VAT
25
TANK-SURGE
5439202
$178,49 Unit Price incl. VAT
26
MOUNT RADIATOR RH BLACK
5256597329
$89,24 Unit Price incl. VAT
27
BRKT-SURGE TANK MNT BLK [M99AM BM]
5261799329
$62,99 Unit Price incl. VAT
28
HOSE-COOLANT RETURN [U99AV BV]
5415936
$29,39 Unit Price incl. VAT
29
HOSE-COOLANT RETURN [U99AV BV]
5415937
$62,99 Unit Price incl. VAT
30
CONNECTOR-TEE 1X1X0.5
7052530
$10,49 Unit Price incl. VAT
31
HOSE-POLY CLEAR 3/16#ODX1/8#ID
8360009170
$18,89 Unit Price incl. VAT
32
SCR-M6X1X16 TR/TX-M
7518936
$7,34 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
