DRIVE TRAIN, MAIN GEARCASE INTERNALS FOR RANGER XP 1000 NORTHSTAR EDITION ULTIMATE TRAIL BOSS FROM 2023

DRIVE TRAIN, GEAR SELECTOR

DRIVE TRAIN, MAIN GEARCASE MOUNTING

ASM-GEARCASE REAR DIFF [INCL ALL]

1334423

$4 950,74 Unit Price incl. VAT

PLUG SOCKET HEAD

3234755

$52,49 Unit Price incl. VAT

PLUG-SOCKET HEAD W/MAG M18X1.5

3234756

$57,74 Unit Price incl. VAT

SCREW 6-LOBE PAN HD M6 X 1 X 16

3234309

$13,64 Unit Price incl. VAT

SCREW HEX FLANGE HEAD M8 X 1.25 X 30

3234898

$17,84 Unit Price incl. VAT

SCREW HEX FLANGE HEAD M6 X 1 X 20

3235206

$13,64 Unit Price incl. VAT

SCREW SOCKET HEAD CAP M6 X 1.0 X 40

3235208

$20,99 Unit Price incl. VAT

SCREW SOCKET HEAD CAP M6 X 1.0 X 18

3235332

$7,34 Unit Price incl. VAT

SCREW CAP HH M8 X 1.25 X 25

3236169

$17,84 Unit Price incl. VAT

NUT LOCK HEX FLANGE NYLON M8 X 1.25

3235210

$14,69 Unit Price incl. VAT

WASHER CUP

3234091

$17,84 Unit Price incl. VAT

WASHER-32.3X42X1.5(115288)

3235211

$19,94 Unit Price incl. VAT

WASHER-35.6X57X1.5(115289)

3235212

$25,19 Unit Price incl. VAT

WASHER 22.70 X 32.0 X 1.5

3235991

$19,94 Unit Price incl. VAT

WASHER 22.5 X 30 X 1.5

3236410

$14,69 Unit Price incl. VAT

PIN DOWEL 6 X 20

3234330

$13,64 Unit Price incl. VAT

PIN SPRING SLOTTED 6 X 12

7043746

$15,74 Unit Price incl. VAT

PIN DOWEL 3 X 40

3236286

$25,19 Unit Price incl. VAT

PIN DOWEL 8 X 10

3236295

$20,99 Unit Price incl. VAT

RING RETAINING BASIC EXTERNAL

7710434

$7,34 Unit Price incl. VAT

RING RETAINING BASIC EXTERNAL 0.75

3233045

$9,44 Unit Price incl. VAT

RING RETAINING BASIC EXTERNAL 0.984

3233106

$10,49 Unit Price incl. VAT

RING RETAINING BASIC EXTERNAL

3233834

$19,94 Unit Price incl. VAT

RING RETAINING SHAFT DIA. 1.375

3233364

$12,59 Unit Price incl. VAT

RING RETAINING BASIC INTERNAL 2.047

3234269

$17,84 Unit Price incl. VAT

RING RETAINING BASIC EXTERNAL 0.428

3234090

$19,94 Unit Price incl. VAT

RING RETAINING

3234205

$20,99 Unit Price incl. VAT

RING RETAINING BASIC EXTERNAL MSR-32

3235214

$17,84 Unit Price incl. VAT

RING-RETAIN VSH-237(130298)

3235216

$19,94 Unit Price incl. VAT

WASHER THRUST 1.187 X 1.500 X .0600

3233378

$17,84 Unit Price incl. VAT

WASHER THRUST 0.446 X 0.88 X 0.025

3234642

$19,94 Unit Price incl. VAT

SPACER 19.4 X 34.0 X 2.0

3235883

$41,99 Unit Price incl. VAT

SEAL TRIPLE LIP VITON HELIX 40X70X7

3235052

$57,74 Unit Price incl. VAT

BEARING NEEDLE CAGE ASSY

3233014

$74,54 Unit Price incl. VAT

BEARING

3233019

$54,59 Unit Price incl. VAT

BEARING BALL 6305 C3 25 X 62 X 17

3233020

$80,84 Unit Price incl. VAT

BEARING BALL 6010 C3 50 X 80 X 10

3233268

$88,19 Unit Price incl. VAT

BEARING BALL 6207 C3 35MMX72MMX17MM

3234065

$80,84 Unit Price incl. VAT

BEARING-NEEDLE 30X35X13-CAGED

3233384

$54,59 Unit Price incl. VAT

BEARING BALL 6012 C3 60 X 95 X 18

3235218

$101,84 Unit Price incl. VAT

BEARING BALL 6303 17 X 47 X 14

3234652

$27,29 Unit Price incl. VAT

BEARING BALL 6903 17 X 30 X 7

3235807

$60,89 Unit Price incl. VAT

BEARING BALL 62/32

3236118

$54,59 Unit Price incl. VAT

SPRING COMPRESSION .92 O.D. X 2.000

3234078

$47,24 Unit Price incl. VAT

SPRING COMPRESSION 0.46 I.D. X 0.73

3234089

$52,49 Unit Price incl. VAT

SPRING TORSION RETURN

3234276

$16,79 Unit Price incl. VAT

SPRING COMPRESSION 0.54 O.D. X 0.44 I.D. X 0.05 WIRE

3234277

$26,24 Unit Price incl. VAT

SPRING COMPRESSION 0.36 O.D. X 1.125

3234578

$26,24 Unit Price incl. VAT

WASHER-SPRING 210393

3235327

$17,84 Unit Price incl. VAT

COVER SECTOR GEARS MACH

3235809

$73,49 Unit Price incl. VAT

TUBE SNORKEL MACH

3236120

$309,74 Unit Price incl. VAT

CARRIER DIFFERENTIAL MACH

3236287

$314,99 Unit Price incl. VAT

GEAR SECTOR 16T

3233839

$68,24 Unit Price incl. VAT

GEAR-SECTOR 31T

3233832

$68,24 Unit Price incl. VAT

FORK PIVOT SHIFT REAR DIFF

3235455

$173,24 Unit Price incl. VAT

PLATE PARK 12 FACE

3235456

$73,49 Unit Price incl. VAT

STAR DETENT

3235982

$68,24 Unit Price incl. VAT

SHAFT-IDLER 29T(285803)

3235223

$204,74 Unit Price incl. VAT

SHAFT REVERSE 25T

3235451

$272,99 Unit Price incl. VAT

GEAR 14T OUTPUT MACH

3236290

$309,74 Unit Price incl. VAT

GEAR 53T OUTPUT

3236291

$488,24 Unit Price incl. VAT

SHAFT FRONT OUTPUT

3236411

$246,74 Unit Price incl. VAT

GEAR 14T OUTPUT DISCONNECT MACH

3236289

$314,99 Unit Price incl. VAT

BELLCRANK ZEUS

3236238

$68,24 Unit Price incl. VAT

COLLAR SHIFT

3234073

$57,74 Unit Price incl. VAT

TUBE VENT 90 -1/4 INCH HOSE

3234230

$19,94 Unit Price incl. VAT

GEAR-LOW 67T(352856)

3235232

$230,99 Unit Price incl. VAT

ENGAGEMENT DOG 6-FACE(352857)

3235233

$241,49 Unit Price incl. VAT

GEAR-46T STAGE 3(352872)

3235236

$204,74 Unit Price incl. VAT

SHAFT-SHIFT(352973)

3235238

$68,24 Unit Price incl. VAT

GEAR 52T

3236435

$157,49 Unit Price incl. VAT

GEAR 48T STAGE 2

3235450

$246,74 Unit Price incl. VAT

SHIFT DOG PARK/LOW (353357)

3235457

$272,99 Unit Price incl. VAT

RAIL-SHIFT SHAFT(353622)

3235542

$52,49 Unit Price incl. VAT

GEAR LOW 25T

3236132

$120,74 Unit Price incl. VAT

CAM PARK

3235983

$283,49 Unit Price incl. VAT

DRUM SHIFT MACH

3235984

$519,74 Unit Price incl. VAT

GEAR REVERSE 56T

3235985

$188,99 Unit Price incl. VAT

GEAR IDLER 39T

3235986

$209,99 Unit Price incl. VAT

PIN DIFFERENTIAL

3236292

$194,24 Unit Price incl. VAT

GEAR 13T SNORKEL

3236412

$272,99 Unit Price incl. VAT

DOG ENGAGEMENT

3236293

$257,24 Unit Price incl. VAT

WELDMENT REAR MOUNT BRACKET

3236342

$68,24 Unit Price incl. VAT

SUBASSEMBLY PAWL DETENT ROLLER

3235452

$68,24 Unit Price incl. VAT

SUBASSEMBLY SHIFT FORK

3235920

$136,49 Unit Price incl. VAT

SUBASSEMBLY PINION 11T

3236140

$545,99 Unit Price incl. VAT

SUBASSEMBLY PINION GEAR

3236288

$257,24 Unit Price incl. VAT

SUBASSEMBLY DIFFERENTIAL

3236285

$719,24 Unit Price incl. VAT

SUBASSY RH CASE

3236693

$750,74 Unit Price incl. VAT

SUBASSEMBLY INPUT 43T/22T/25T

3236691

$645,74 Unit Price incl. VAT

SUBASSY LH CASE

3236714

$850,49 Unit Price incl. VAT

RETAINER-FORK

3234934

$19,94 Unit Price incl. VAT

COVER-BEARING CNTR DR.

3235241

$89,24 Unit Price incl. VAT

WASHER THRUST 40.83 X 56.25 X 0.38

3236294

$20,99 Unit Price incl. VAT

BRACKET REAR MOUNT

3236343

$68,24 Unit Price incl. VAT

SOLENOID

3235478

$545,99 Unit Price incl. VAT

SENSOR-SPEED TRANS

4013908

4082135

$204,74 Unit Price incl. VAT

SWITCH ROTARY 2 PIN RESISTIVE

7662299

$209,99 Unit Price incl. VAT

100

SEAL TRIPLE LIP 25 X 55 X 8

3236135

$104,99 Unit Price incl. VAT

101

O-RING 2.989 I.D. X 0.07

3236136

$17,84 Unit Price incl. VAT

102

SEAL TRIPLE LIP 32 X 49 X 8 VITON

3236141

$110,24 Unit Price incl. VAT

103

O-RING

3234302

$13,64 Unit Price incl. VAT

104

O-RING -012 VITON

3233836

$12,59 Unit Price incl. VAT

105

O-RING -014 VITON

3233828

$12,59 Unit Price incl. VAT

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
