1
Engine displacement
750
2
Year
2004
3
Trim
MSX 150 - W045305CA
4
Parts Catalog
FUEL TANK
5
Parts Diagram
Parts Catalog
SEAT
by
FUEL SYSTEM
FUEL TANK
1
2
3
4
5
6
6
7
7
8
8
9
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
1
1
2
3
4
4
4
4
4
4
5
6
7
8
9
10
10
10
11
11
11
12
13
14
15
16
17
18
1
NUT-DFI FUEL PUMP
5433259
Not Available
2
Pump Fuel
2410374
Not Available
3
Strap Connecting
5412305
$10,70 Unit Price incl. VAT
4
GASKET-DFI FUEL PUMP
5411636
Not Available
5
Tank Fuel
5434874
Not Available
6
Cover Strap
5521615
Not Available
7
Asm. Strap Fuel Tank (Incl. 2 3)
2632743
Not Available
8
Bracket Tank Strap
5247361
$4,29 Unit Price incl. VAT
9
RVT-3/16(.020-.200)AL-BULBX-B
7621485
$2,09 Unit Price incl. VAT
10
Pad
5812564
$30,54 Unit Price incl. VAT
11
CLAMP HOSE S.S.(10)
7080451
$13,64 Unit Price incl. VAT
12
Hose Fuel Fill
5412441
Not Available
13
CLAMP HOSE SS.
7080766
$3,35 Unit Price incl. VAT
14
Gasket Fuel Fill
5812560
$27,92 Unit Price incl. VAT
15
INLET FUEL
5433553
$22,46 Unit Price incl. VAT
16
SCREW(10)
7511873
Not Available
17
SEAL FUEL CAP
5411305
Not Available
18
CAP FUEL RATCHET ASM. Substituted by 2201745
2520177
Not Available
19
CHAIN BEAD FUELCAP RETAIN.
7080710
Not Available
20
COUPLING
7080442
Not Available
21
RIVET(50)
7621229
Not Available
22
NUT INLET FUEL
5433621
$25,61 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
