1
Engine displacement
500
2
Year
2002
3
Trim
SPORTSMAN 6X6 - A02CL50AA
4
Parts Catalog
REAR CAB SEAT
5
Parts Diagram
Parts Catalog
by
EXHAUST SYSTEM
REAR CAB SEAT
1
Rivet
7661645
Not Available
2
CAB-REAR MODIFIED 6X6 EB GREEN Substituted by 2632158-195
5433428195
Not Available
3
SCR-1/4-20X1 1/4-TRIRD HX WH-Y
7512242
$4,19 Unit Price incl. VAT
4
WASHER-FL .281X.750X.062-Y
7555859
$2,09 Unit Price incl. VAT
5
Covering Seat Black
2682960070
Not Available
5
COVER SEAT 6X6 BLK.SVC
2682519070
Not Available
5
SEAT BLK Substituted by 2682520-070 (Incl. 7)
2682701070
Not Available
5
Asm. Seat Black [Incl. 6]
2682959070
Not Available
6
BUMPER-RUBBER
5412067
$7,34 Unit Price incl. VAT
7
FRAME BLK
1013323067
Not Available
8
BUMPER RUBBER
5410414
$6,29 Unit Price incl. VAT
9
BOLT(10)
7512240
$7,34 Unit Price incl. VAT
10
PLUG-NYLON
5432798
$10,49 Unit Price incl. VAT
11
Lever Box
1013307067
$343,34 Unit Price incl. VAT
12
NUT NYLOK FLANGED 1/4 [INTL]
7542153
$3,14 Unit Price incl. VAT
13
Spring
7041879
Not Available
14
RIVET-3/16-.090-.290
7661637
$2,09 Unit Price incl. VAT
15
GUARD CLUTCH BLK
5242953067
Not Available
16
SCR-1/4-20X1 HX/WH/TAP/R GR5-Y
7515179
$4,19 Unit Price incl. VAT
17
Guard Rock
5432763
$167,99 Unit Price incl. VAT
18
WASHER FLAT .344x.875x.063
7555734
$1,56 Unit Price incl. VAT
19
NUT-5/16-18 NYLOK-Y [INTL]
7542324
$1,56 Unit Price incl. VAT
20
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
21
BOLT
7512392
$9,44 Unit Price incl. VAT
22
Mount Strut Rear
1040293067
Not Available
23
SCREW
7512279
$1,56 Unit Price incl. VAT
24
Footwell Black LH
5432221070
$430,49 Unit Price incl. VAT
24
FOOTWELL-NYLON RH BLK
5433219070
$430,49 Unit Price incl. VAT
24
Footwell Black RH
5434417070
$430,49 Unit Price incl. VAT
25
SCR-TFHFL-1/4-20X0.75 CHS ZY3
7512232
$2,09 Unit Price incl. VAT
26
Guard Mud Rear LH
5433429
Not Available
26
Guard Mud Rear RH
5433430
Not Available
27
NUT U-TYPE SPEED
7670057
$2,09 Unit Price incl. VAT
28
Foil Foam Rear Fender
5811111
$62,99 Unit Price incl. VAT
29
Foil Rear Cab Front
5811106
$16,79 Unit Price incl. VAT
30
Foil Foam
5811087
Not Available
31
Decal 4 Stroke Carb/Filter Information
7079902
Not Available
32
NUT-NYLOC 10-24 Y
7541925
$1,56 Unit Price incl. VAT
33
WASHER-.20X.67X.048-Y
7555792
$9,44 Unit Price incl. VAT
34
Screw
7512085
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
