1
Engine displacement
500
2
Year
2008
3
Trim
RANGER 4X4 500 EFI - R08RH50AF/AR/AT
4
Parts Catalog
STEERING
5
Parts Diagram
Parts Catalog
REAR SUSPENSION STABILIZER BAR
by
FRONT SUSPENSION STRUT
STEERING
22
23
24
25
26
27
28
1
BOOT SEAL ROD END
5411920
5412929
$20,99 Unit Price incl. VAT
2
ROD END [INCL. 1]
7061054
7061138
$104,99 Unit Price incl. VAT
3
NUT-1/2-20 LH JAM
7547028
$4,19 Unit Price incl. VAT
4
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
5
BELLOWS CLAMP SMALL
7080978
$4,19 Unit Price incl. VAT
6
BOOT PASSENGER SIDE RACK
5412013
$104,99 Unit Price incl. VAT
7
CLAMP LARGE BELLOWS
7080979
$10,49 Unit Price incl. VAT
8
SCR-HH-5/16-18X3.75 GR5 ZY3
7515382
$4,19 Unit Price incl. VAT
9
SCREW(10)
7515434
Not Available
10
SCR-HH-M8X1.25X30 8.8 ZY3
7517924
$8,39 Unit Price incl. VAT
11
WASHER-5/16 SPRING LK-MED-Y
7552901
$2,09 Unit Price incl. VAT
12
BUSHING SHAFT STEERING
5434106
$16,79 Unit Price incl. VAT
13
BUSHING-.781 X1.250X.060-Y
7556301
$6,29 Unit Price incl. VAT
14
Wheel Steering
1821334
1823678
$241,49 Unit Price incl. VAT
15
NUT
7547188
$10,49 Unit Price incl. VAT
16
CAP-STEERING WHEEL
5436536
$62,99 Unit Price incl. VAT
17
BOLT 5/16-18X3/4
7512371
$9,44 Unit Price incl. VAT
18
WASHER WAVE
7556063
$5,76 Unit Price incl. VAT
19
Shaft Steering Upper
1821018
$115,49 Unit Price incl. VAT
20
Shaft Steering w/Joints Lower
1822732
$540,74 Unit Price incl. VAT
21
NUT-3/8-24(NYLOK)-Y
7542439
$2,09 Unit Price incl. VAT
22
NUT-5/16-18 NYLOK-Y [INTL]
7542324
$1,56 Unit Price incl. VAT
23
BOOT DRIVERS SIDE RACK
5412012
$115,49 Unit Price incl. VAT
24
SCR-HXFL-M10X1.25X65 10.9 ZY3
7517909
$10,49 Unit Price incl. VAT
25
WASHER-FL 10.7X21.9X2.5-Y
7556099
$3,14 Unit Price incl. VAT
26
NUT-M10X1.25-HX-LOCK-Y(10)
7547177
7548155
$1,56 Unit Price incl. VAT
27
PIN COTTER
7661203
$2,09 Unit Price incl. VAT
28
Asm. Gear Box Steering [Incl. 1-7 23]
1822636
$908,24 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
