1
Engine displacement
1200
2
Year
2001
3
Trim
GENESIS I - W015098D
4
Parts Catalog
SHROUD
5
Parts Diagram
Parts Catalog
STARTING MOTOR
by
FUEL TANK
SHROUD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1
2
3
4
5
5
6
7
8
9
10
11
12
12
13
13
13
14
14
15
16
17
18
18
19
19
20
21
22
23
23
24
25
26
27
28
29
30
31
32
33
34
34
35
36
37
38
39
40
41
42
43
1
2
3
4
5
5
6
7
8
9
10
11
12
12
13
13
13
14
14
15
16
17
18
18
19
19
20
21
22
23
23
24
25
26
27
28
29
30
31
32
33
34
34
35
36
37
38
39
40
41
42
43
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
17
18
18
18
18
19
19
19
19
19
19
19
19
19
1
2
3
3
4
4
5
5
6
7
8
9
9
10
10
11
12
13
13
14
14
15
15
16
18
19
19
20
21
22
22
1
2
3
3
4
4
5
5
6
7
8
9
9
10
10
11
12
13
13
14
14
15
15
16
18
19
19
20
21
22
22
1
2
3
3
4
4
5
5
6
7
8
9
9
10
10
11
12
13
13
14
14
15
15
16
18
19
19
20
21
22
22
1
2
3
3
4
4
5
5
6
7
8
9
9
10
10
11
12
13
13
14
14
15
15
16
18
19
19
20
21
22
22
1
2
3
3
4
4
5
5
6
7
8
9
9
10
10
11
12
13
13
14
14
15
15
16
18
19
19
20
21
22
22
1
2
2
3
4
5
5
6
7
8
9
10
10
11
11
12
13
13
14
14
15
16
1
GAUGE MFD ANALOG/DIGITAL
3280292
$890,39 Unit Price incl. VAT
2
GASKET-MFI
5411738
$8,39 Unit Price incl. VAT
3
CONNECTOR-DEUTCHE 4PIN W/PLUGS
4010281
$27,92 Unit Price incl. VAT
4
PITOT LINE 90DEG FORMED 235CM. Substituted by 8450070-277
8450070235
$35,69 Unit Price incl. VAT
5
SPRING MOUNTING MFI
7041931
$2,93 Unit Price incl. VAT
6
MFI BUTTON REPLACEMENT KIT
2201593
$37,16 Unit Price incl. VAT
7
BEZEL-MFI OVERLAY
3280342
$38,42 Unit Price incl. VAT
8
LID-CONSOLE BLACK MET
54341761093
Not Available
9
SEAL-BULB CONSOLE LID
5521579
Not Available
10
NUT 6 MM. S.S.(10)
7546705
$9,44 Unit Price incl. VAT
11
PAD-CONSOLE
5812235
Not Available
12
SCREW(10)
7517668
$3,35 Unit Price incl. VAT
13
WASHER FLAT S.S.(10)
7555831
Not Available
14
NUT NYLOCK SS.(10)
7546704
$2,82 Unit Price incl. VAT
15
WASHER-6.4MMX18X1.6 SS
7556094
$9,44 Unit Price incl. VAT
16
HOOK-CONSOLE LATCH
5245455
Not Available
17
SCREW (10)
7517669
Not Available
18
GASKET-MIRROR LH
5411557
$7,97 Unit Price incl. VAT
18
GASKET-MIRROR RH
5411558
$7,97 Unit Price incl. VAT
19
MIRROR LH BLACK ASM. (LH)
2631972070
$192,14 Unit Price incl. VAT
19
MIRROR RH BLACK ASM. (RH)
2631973070
$171,66 Unit Price incl. VAT
20
RIVET-POP (50)
7661042
$1,77 Unit Price incl. VAT
21
MOUNT SHROUD
1820725
$23,82 Unit Price incl. VAT
22
NUT-HEX M8X1.25 NYLOCK-SS [S99CR]
7546804
$2,09 Unit Price incl. VAT
23
WASHER FLAT S.S.(10)
7555839
$0,93 Unit Price incl. VAT
24
NUT
7541931
$9,44 Unit Price incl. VAT
25
BRKT SUPPORT SHROUD
5244673
Not Available
26
BOLT(10)
7516807
Not Available
27
GROMMET-DECK WIRE HARNESS
5411664
Not Available
28
STRAP-TOOL KIT LOWER
2690151
Not Available
29
COVER-WIRE SHROUD BLK
5433210070
Not Available
30
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
31
STRAP-TOOL KIT UPPER
2690150
Not Available
32
RING-RETAINING .25 STUD
7710517
Not Available
33
SCREW S.S.(10)
7516805
$1,14 Unit Price incl. VAT
34
WASHER LOCK(10)
7552613
Not Available
35
SHROUD-STEER NO REV BLK MET
54342101093
Not Available
36
BUMPER DOOR/SHROUD
5812076
$15,95 Unit Price incl. VAT
37
PLATE LATCH RECEIVER
5244670
Not Available
38
WASHER FLAT S.S.(10)
7555837
$2,09 Unit Price incl. VAT
39
SCR-#10-32X3/4 FLAT SOC SS(10)
7517879
Not Available
40
PIN-HINGE CONSOLE
5333698
Not Available
41
SPRING-TORTION CONSOLE 070.SS [Item NotAvailable]
7042007
Not Available
42
HINGE-CONSOLE 3/16 PIN
5433384
Not Available
43
LATCH ASM CONSOLE
2653011
$46,40 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.

Other Parts for GENESIS I - W015098D

HULL BODY

HULL BODY

for GENESIS I - W015098D from 2001

HULL BODY

HULL BODY

for GENESIS I - W015098D from 2001

FRONT STORAGE COMPARTMENT

FRONT STORAGE COMPARTMENT

for GENESIS I - W015098D from 2001

DECALS

DECALS

for GENESIS I - W015098D from 2001

STEERING

STEERING

for GENESIS I - W015098D from 2001

STEERING

STEERING

for GENESIS I - W015098D from 2001

DRIVE SYSTEM

DRIVE SYSTEM

for GENESIS I - W015098D from 2001

PROPULSION

PROPULSION

for GENESIS I - W015098D from 2001

WATER INLET

WATER INLET

for GENESIS I - W015098D from 2001

BILGE PUMP

BILGE PUMP

for GENESIS I - W015098D from 2001

WATER SIPHON

WATER SIPHON

for GENESIS I - W015098D from 2001

ELECTRICAL BOX

ELECTRICAL BOX

for GENESIS I - W015098D from 2001

BATTERY BOX

BATTERY BOX

for GENESIS I - W015098D from 2001

CRANKSHAFT AND PISTON

CRANKSHAFT AND PISTON

for GENESIS I - W015098D from 2001

OIL PUMP

OIL PUMP

for GENESIS I - W015098D from 2001

EMM

EMM

for GENESIS I - W015098D from 2001

STARTING MOTOR

STARTING MOTOR

for GENESIS I - W015098D from 2001

SHROUD

SHROUD

for GENESIS I - W015098D from 2001

FUEL TANK

FUEL TANK

for GENESIS I - W015098D from 2001

FUEL SYSTEM

FUEL SYSTEM

for GENESIS I - W015098D from 2001

SEAT

SEAT

for GENESIS I - W015098D from 2001

OIL TANK

OIL TANK

for GENESIS I - W015098D from 2001

REVERSE

REVERSE

for GENESIS I - W015098D from 2001

EXHAUST SYSTEM

EXHAUST SYSTEM

for GENESIS I - W015098D from 2001

AIR VENT

AIR VENT

for GENESIS I - W015098D from 2001

COOLING SYSTEM

COOLING SYSTEM

for GENESIS I - W015098D from 2001

ENGINE MOUNTING

ENGINE MOUNTING

for GENESIS I - W015098D from 2001

CRANKCASE

CRANKCASE

for GENESIS I - W015098D from 2001

MANIFOLD IGNITION

MANIFOLD IGNITION

for GENESIS I - W015098D from 2001

THROTTLE BODY

THROTTLE BODY

for GENESIS I - W015098D from 2001

TOOL KIT

TOOL KIT

for GENESIS I - W015098D from 2001

POLARIS GENESIS I - W015098D 2001

GENESIS I - W015098D

GENESIS I - W015098D

Model : GENESIS

Engine capacity : 1200

Year : 2001

New and OEM parts
International Shipping
Official price POLARIS
A team of experts at your service
Secure Payment
By your side since 2001
Customer Reviews
4.2 /5
1764 Reviews
View all reviews
Spare parts catalogue for all brands
