1
Engine displacement
0
2
Year
1996
3
Trim
EURO STORM - E965782
4
Parts Catalog
REAR TORQUE ARM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159C004)
5
Parts Diagram
Parts Catalog
FRONT TORQUE ARM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159C003)
by
FOX SHOCK
REAR TORQUE ARM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159C004)
1
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
19
20
21
22
22
23
23
23
23
24
24
24
25
26
26
27
28
28
28
28
29
30
31
32
33
34
35
35
1
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
19
20
21
22
22
23
23
23
23
24
24
24
25
26
26
27
28
28
28
28
29
30
31
32
33
34
35
35
1
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
19
20
21
22
22
23
23
23
23
24
24
24
25
26
26
27
28
28
28
28
29
30
31
32
33
34
35
35
1
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
19
20
21
22
22
23
23
23
23
24
24
24
25
26
26
27
28
28
28
28
29
30
31
32
33
34
35
35
1
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
19
20
21
22
22
23
23
23
23
24
24
24
25
26
26
27
28
28
28
28
29
30
31
32
33
34
35
35
1
BOLT NYLOC BLACK(10) Substituted by 7515432 (650 Only)
7515493
Not Available
2
SHAFT R.TORQUE UPPER
5020845
$115,49 Unit Price incl. VAT
3
ARM R.TORQUE BLK Substituted by 2200914 (X-10 Blk)
1541024067
Not Available
4
SHAFT LOW RR TORQUE
5020843
Not Available
5
SCR-RHCAR-5/16-18X0.75 GR5 ZY3
7512377
$9,44 Unit Price incl. VAT
6
BOLT EYE
7010050
Not Available
7
FITTING LUBRICATION
7080433
$2,09 Unit Price incl. VAT
8
WASHER-.250X.563X.047 WRGHT-Y
7558203
$6,29 Unit Price incl. VAT
9
NUT FLANGE
7542321
$2,09 Unit Price incl. VAT
10
LOCK BOLT MECHANICAL
5211649
Not Available
11
BOLT(10)
7515526
7517731
$2,09 Unit Price incl. VAT
12
COLLAR-BRG. LOCK
5010155
Not Available
13
SCREW SOCKET SET
7512257
$7,34 Unit Price incl. VAT
14
WASHER THRUST(10) Substituted by 7555871
7555862
$10,49 Unit Price incl. VAT
15
WHEEL CARRIER
1543023
Not Available
16
WASHER THRUST
7555787
$10,49 Unit Price incl. VAT
17
ROLLER SPRING ADJ.
5431168
Not Available
18
SPRING RH TORS(.421DIA) (.421) Med.
7041462067
$209,99 Unit Price incl. VAT
18
SPRING LH TORS(.437/77) (437)
7041465067
Not Available
18
SPRING LH TORS(.406DIA) (.406) Std.
7041463067
Not Available
18
SPRING RH TORS(.406DIA) (.406) Std.
7041464067
Not Available
18
SPRING RH TORS(.437/77) (437)
7041466067
$182,69 Unit Price incl. VAT
18
SPRING LH TORS(.421DIA) (.421) Med.
7041461067
Not Available
19
SLEEVE TORSION SPRING
5431923
$11,54 Unit Price incl. VAT
20
CLIP PUSH ON
7080394
$4,19 Unit Price incl. VAT
21
SCR-5/16-18X1-HX/FLG-GR5-Y
7515307
$7,34 Unit Price incl. VAT
22
WASHER-.328X1.25X16GA FL-Y
7555716
$3,14 Unit Price incl. VAT
23
STRAP-LIMITER RR SA (RR SA)(SKS)
5411062
Not Available
23
STRAP LIMITER (RR QA)
5411061
Not Available
24
BUSHING PIVOT TUBE
5020561
$2,61 Unit Price incl. VAT
25
NUT FLEXLOC
7542411
$6,29 Unit Price incl. VAT
26
WASHER WAVE SPRING(10)
7555795
$2,09 Unit Price incl. VAT
27
SPACER
5333420
$19,20 Unit Price incl. VAT
28
ROD SHOCK (XTRA 10)133
1541021067
Not Available
28
ROD SHOCK
1541015067
Not Available
29
SCR-3/8-24X3 3/4 HX CP GR5-Y
7515472
$4,19 Unit Price incl. VAT
30
NUT FLEX-LOC(10)
7542303
$11,54 Unit Price incl. VAT
31
BUSHING
5430537
$7,34 Unit Price incl. VAT
32
BUSHING R.SHOCK
5333030
Not Available
33
SCR-HH-5/16-18X1.75 GR5 ZY3
7512329
$7,34 Unit Price incl. VAT
34
SHOCK GAS IFP R.TRACK (Incl. 1-23)
7041444
Not Available
35
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
36
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.

Other Parts for EURO STORM - E965782

TUNNEL

TUNNEL

for EURO STORM - E965782 from 1996

NOSEPAN

NOSEPAN

for EURO STORM - E965782 from 1996

NOSEPAN

NOSEPAN

for EURO STORM - E965782 from 1996

INSTRUMENTS STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STOR (4931593159B001)

INSTRUMENTS STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STOR (4931593159B001)

for EURO STORM - E965782 from 1996

HOOD

HOOD

for EURO STORM - E965782 from 1996

CONTROLS STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STORM (4931593159B003)

CONTROLS STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STORM (4931593159B003)

for EURO STORM - E965782 from 1996

FRONT SUSPENSION AND SKI STORM 0965782, STORM SKS 0965582, EURO STORM E9657 (4931593159B004)

FRONT SUSPENSION AND SKI STORM 0965782, STORM SKS 0965582, EURO STORM E9657 (4931593159B004)

for EURO STORM - E965782 from 1996

COOLING SYSTEM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159B010)

COOLING SYSTEM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159B010)

for EURO STORM - E965782 from 1996

TOOL KIT/BOX STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EU (4931593159B012)

TOOL KIT/BOX STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EU (4931593159B012)

for EURO STORM - E965782 from 1996

SUSPENSION STORM SKS 0965582, EURO STORM SKS E965582, AND STORM RMK 0965982 (4931593159B013)

SUSPENSION STORM SKS 0965582, EURO STORM SKS E965582, AND STORM RMK 0965982 (4931593159B013)

for EURO STORM - E965782 from 1996

SUSPENSION STORM 0965782 AND EURO STORM E965782 (4931593159C001)

SUSPENSION STORM 0965782 AND EURO STORM E965782 (4931593159C001)

for EURO STORM - E965782 from 1996

FOX SHOCK

FOX SHOCK

for EURO STORM - E965782 from 1996

DRIVE CLUTCH ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782 (4931593159C008)

DRIVE CLUTCH ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782 (4931593159C008)

for EURO STORM - E965782 from 1996

DRIVEN CLUTCH ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E96578 (4931593159C009)

DRIVEN CLUTCH ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E96578 (4931593159C009)

for EURO STORM - E965782 from 1996

DRIVE TRAIN ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, (4931593159C010)

DRIVE TRAIN ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, (4931593159C010)

for EURO STORM - E965782 from 1996

ENGINE MOUNTING STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159C011)

ENGINE MOUNTING STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159C011)

for EURO STORM - E965782 from 1996

WATER PUMP STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STOR (4931593159D003)

WATER PUMP STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STOR (4931593159D003)

for EURO STORM - E965782 from 1996

PISTON CRANKSHAFT STORM 0965782, STORM SKS 0965582, EURO STORM E965782 (4931593159D004)

PISTON CRANKSHAFT STORM 0965782, STORM SKS 0965582, EURO STORM E965782 (4931593159D004)

for EURO STORM - E965782 from 1996

CARBURETOR STORM 0965782, STORM SKS 0965582, EURO STORM E965782, E (4931593159D005)

CARBURETOR STORM 0965782, STORM SKS 0965582, EURO STORM E965782, E (4931593159D005)

for EURO STORM - E965782 from 1996

OIL PUMP ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EU (4931593159D007)

OIL PUMP ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EU (4931593159D007)

for EURO STORM - E965782 from 1996

DECALS

DECALS

for EURO STORM - E965782 from 1996

NOSEPAN FOIL

NOSEPAN FOIL

for EURO STORM - E965782 from 1996

CONSOLE WIRE HARNESS

CONSOLE WIRE HARNESS

for EURO STORM - E965782 from 1996

HOOD

HOOD

for EURO STORM - E965782 from 1996

INSTRUMENTS

INSTRUMENTS

for EURO STORM - E965782 from 1996

STEERING STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STORM S (4931593159B006)

STEERING STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STORM S (4931593159B006)

for EURO STORM - E965782 from 1996

STEERING ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EU (4931593159B007)

STEERING ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EU (4931593159B007)

for EURO STORM - E965782 from 1996

BRAKE STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STORM SKS (4931593159B008)

BRAKE STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STORM SKS (4931593159B008)

for EURO STORM - E965782 from 1996

CHAINCASE ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, E (4931593159B009)

CHAINCASE ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, E (4931593159B009)

for EURO STORM - E965782 from 1996

FRONT TORQUE ARM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159C003)

FRONT TORQUE ARM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159C003)

for EURO STORM - E965782 from 1996

REAR TORQUE ARM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159C004)

REAR TORQUE ARM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159C004)

for EURO STORM - E965782 from 1996

FOX SHOCK

FOX SHOCK

for EURO STORM - E965782 from 1996

FOX SHOCK

FOX SHOCK

for EURO STORM - E965782 from 1996

EXHAUST SYSTEM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO S (4931593159C012)

EXHAUST SYSTEM STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO S (4931593159C012)

for EURO STORM - E965782 from 1996

OIL TANK AIR BOX STORM 0965782, STORM SKS 0965582, EURO STORM E9 (4931593159C013)

OIL TANK AIR BOX STORM 0965782, STORM SKS 0965582, EURO STORM E9 (4931593159C013)

for EURO STORM - E965782 from 1996

CRANKCASE ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, E (4931593159C014)

CRANKCASE ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, E (4931593159C014)

for EURO STORM - E965782 from 1996

CYLINDER MANIFOLD ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM (4931593159D001)

CYLINDER MANIFOLD ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM (4931593159D001)

for EURO STORM - E965782 from 1996

FUEL PUMP STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STORM (4931593159D008)

FUEL PUMP STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO STORM (4931593159D008)

for EURO STORM - E965782 from 1996

MAGNETO ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159D009)

MAGNETO ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782, EURO (4931593159D009)

for EURO STORM - E965782 from 1996

RECOIL STARTER ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E9657 (4931593159D010)

RECOIL STARTER ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E9657 (4931593159D010)

for EURO STORM - E965782 from 1996

SEAT GAS TANK

SEAT GAS TANK

for EURO STORM - E965782 from 1996

POLARIS EURO STORM - E965782 1996

EURO STORM - E965782

EURO STORM - E965782

Model : STORM

Year : 1996

New and OEM parts
International Shipping
Official price POLARIS
A team of experts at your service
Secure Payment
By your side since 2001
Customer Reviews
4.2 /5
1764 Reviews
View all reviews
Spare parts catalogue for all brands
