1
Engine displacement
500
2
Year
2000
3
Trim
SPORTSMAN 500 - A00CH50AK
4
Parts Catalog
CABIN
5
Parts Diagram
Parts Catalog
by
REAR RACK MOUNTING
CABIN
1
SCR-TFHFL-1/4-20X0.75 CHS ZY3
7512232
$2,09 Unit Price incl. VAT
2
CAB FRONT SVC OLV. GR. Substituted by 2632299-191 (A99CH50(AA)(EA))
2631987191
Not Available
2
CAB FRONT SVC GUN METAL (AL)
2632299317
Not Available
2
CAB FRONT SVC PORCHE RED Substituted by 2632299-136 (A99CH50(AB)(EB))
2631987136
Not Available
2
CAB FRONT SVC M.O. CAMO Substituted by 2632306-283
2632064283
Not Available
2
CAB ASM FRT SVC MD.YELLOW Substituted by 2632299-053 (AE)(AK)
2631987053
Not Available
2
CAB FRONT SVC B.U. CAMO Substituted by 2632409-283 (AC)(AJ)(If built after 5/15/00)
2632306283
Not Available
3
COVER-FRONT OLIVE GREEN (A99CH50(AA)(EA))
5432088191
Not Available
3
COVER FRONT P.RED
5432088136
Not Available
3
COVER-FRONT GUNMETAL (AL)
5432088317
Not Available
3
COVER-FRONT BASIC M. O. CAMO Substituted by 5433290-283A
5433290283
Not Available
3
Cover Front Med Yellow
5432088053
$159,06 Unit Price incl. VAT
4
Clip Spring
7670085
$19,94 Unit Price incl. VAT
5
NUT U-TYPE SPEED
7670057
$2,09 Unit Price incl. VAT
6
SCR-1/4-20X.88 HXWR TAPR GR5 Y
7517312
$2,09 Unit Price incl. VAT
7
Rivet
7661645
Not Available
8
NUT PUSH-ON
7670068
$4,19 Unit Price incl. VAT
9
Shield Deflector [LH]
5811917
$11,96 Unit Price incl. VAT
10
CLIP-FIR TREE DART 6.35MM
7670090
$2,09 Unit Price incl. VAT
11
CLIP ROUTING
7670109
$4,19 Unit Price incl. VAT
12
DESC NOT_AVAILABLE
5411778
Not Available
13
GUARD-SPLASH SPORTMAN RH BLK
5244914067
Not Available
13
GUARD-SPLASH SPORTMAN LH BLK
5244913067
$45,14 Unit Price incl. VAT
14
SCR-1/4-20X1.00 TR/TX-M
7517685
$3,14 Unit Price incl. VAT
15
WASHER(10) Substituted by 7558221
7555931
7558221
$4,19 Unit Price incl. VAT
16
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
17
Guard Mud Front LH
5431798070
$108,14 Unit Price incl. VAT
17
Guard Mud Front RH
5431799070
$125,99 Unit Price incl. VAT
18
NUT-NYLOC 10-24 Y
7541925
$1,56 Unit Price incl. VAT
19
WASHER-.20X.67X.048-Y
7555792
$9,44 Unit Price incl. VAT
20
PANEL/FOIL RH GUN METAL (AL)
2620085317
$179,54 Unit Price incl. VAT
20
PANEL/FOAM LH GUN METAL (AL)
2632289317
Not Available
20
ASM-PANEL/FOAM LH MO CAMO Substituted by 2632317-283 (AC)
2632286283
Not Available
20
PANEL/FOIL ASM RH P.RED (Incl. Foil & Foam)
2620085136
Not Available
20
ASM-PANEL/FOAM LH MO CAMO (AJ)
2632317283
$278,24 Unit Price incl. VAT
20
Panel w/Foil Side Med Yellow RH
2620085053
Not Available
20
PANEL LH SIDE P.RED
5431809136
Not Available
20
PANEL/FOIL RH M.O. CAMO
2632065283
$290,84 Unit Price incl. VAT
20
PANEL/FOIL ASM RH OLV.GRN. (Incl. Foil & Foam)
2620085191
Not Available
20
PANEL LH SIDE OLV.GREEN
5431809191
Not Available
20
PANEL SIDE LH MD.YELLOW (AE)(AK)
5431809053
$179,54 Unit Price incl. VAT
21
FOIL FOAM SIDEPANEL
5810996
$104,99 Unit Price incl. VAT
22
Foil Side Panel GEN IV RH
5811491
Not Available
23
Screw
7512085
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
