1
Engine displacement
400
2
Year
2001
3
Trim
SPORTSMAN 400 - A01CH42AA
4
Parts Catalog
HANDLEBAR HEADLIGHT POD
5
Parts Diagram
Parts Catalog
WISHBONES
by
DRIVE CLUTCH
HANDLEBAR HEADLIGHT POD
1
2
2
3
3
3
4
4
14
6
7
7
8
9
10
11
12
13
13
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
27
28
29
30
31
32
33
34
34
34
34
34
34
35
36
37
38
39
1
2
2
3
3
3
4
4
14
6
7
7
8
9
10
11
12
13
13
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
27
28
29
30
31
32
33
34
34
34
34
34
34
35
36
37
38
39
1
2
2
3
3
3
4
4
14
6
7
7
8
9
10
11
12
13
13
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
27
28
29
30
31
32
33
34
34
34
34
34
34
35
36
37
38
39
1
SPEEDOMETER 3.38# 6-PULSE (AA)(AB)(AE)(AF)(AJ)(AK)
3280363
Not Available
2
PANEL-INDICATOR SVC STD PVT
4010459
Not Available
2
BULB-INDICATOR HOBBS
4010416
$18,89 Unit Price incl. VAT
3
SCREW(10)
7511881
$2,09 Unit Price incl. VAT
4
CLIP-SCREW #8/10 .03-.10 PANEL
7670127
$17,84 Unit Price incl. VAT
5
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
6
TUBE-HANDLEBAR GEN 4 POD BLK
5242987067
$178,49 Unit Price incl. VAT
7
Block Handlebar Retainer
5630616067
Not Available
7
Kit Handlebar Block [Incl. Blocks and 7 11 29]
2200774
Not Available
8
Nut
7541933
$7,34 Unit Price incl. VAT
9
WASHER LOCK (S.S.)(10)
7555868
Not Available
10
WASHER FLAT
7558212
$1,56 Unit Price incl. VAT
11
SCREW(10)
7515189
7515189-CO
$2,09 Unit Price incl. VAT
12
Clamp Speedometer
3280291
Not Available
13
POD-HEADLIGHT UPPER PORCHE RED (AB)(EB)
5433763136
Not Available
13
Pod Headlight Upper Med Yellow
5433763053
Not Available
13
POD-HEADLIGHT UPPER OLIVE GRN (AA)
5433763191
Not Available
14
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
15
Spacer Switch
5433903
Not Available
16
SWITCH-HANDLEBAR H/L/O REV/OR
4010262
$383,24 Unit Price incl. VAT
17
Grip Handlebar
5433834070
$52,49 Unit Price incl. VAT
18
PLUG-HOLE .25 FLUSH (BPF-1/4)
5432952
$12,59 Unit Price incl. VAT
19
SCREW SET
7517625
$9,44 Unit Price incl. VAT
20
Bracket Pod Mounting
5244969067
5244969-329
$68,24 Unit Price incl. VAT
21
SCREW(10)
7517317
$6,29 Unit Price incl. VAT
22
KNOB ADJUSTING
4032079
$52,49 Unit Price incl. VAT
23
BOOT HEADLIGHT
5411120
$52,49 Unit Price incl. VAT
24
Collar Locking
4032077
$52,49 Unit Price incl. VAT
25
Lens and Reflector
4032075
Not Available
25
BULB HALOGEN
2870448
$36,74 Unit Price incl. VAT
26
Rod Adjusting
4032078
Not Available
27
O RING-.549X.755X1.03
5410163
$3,14 Unit Price incl. VAT
28
Cable Choke
7081008
$152,24 Unit Price incl. VAT
29
NUT NYLOK
7542122
$2,09 Unit Price incl. VAT
30
Asm. 12V Power Plug
4010283
Not Available
31
Cap Rubber
5411744
Not Available
32
CLIP CABLE RETAIN (10)
7080631
Not Available
33
Pod Headlight Lower
5433762070
Not Available
34
SWITCH IGNITION (Incl. Key)
4110264
4012163
$204,74 Unit Price incl. VAT
34
Blank Key Series 2200 2300 2700 2800. NOTE: YOUR KEY CAN BE DUPLICATED ONLY BY OBTAINING A KEY BLANK FROM POLARIS AND HAVING IT CUT BY MATING IT WITH YOUR EXISTING KEY.
4010321
4083604
$27,29 Unit Price incl. VAT
34
BLANK KEY SERIES 2000 2100 6700 6800 [NOTE:YOUR KEY CAN BE DUPLICATED ONLY BY OBTAINING A KEY BLANK FROM POLARIS AND HAVING IT CUT BY MATING IT WITH YOUR EXISTING KEY]
4010278
4083605
$27,29 Unit Price incl. VAT
35
Cover-Key
5433534
5465307
$26,24 Unit Price incl. VAT
36
NUT CHOKE
7080922
$5,76 Unit Price incl. VAT
37
Sensor
4010298
$220,49 Unit Price incl. VAT
38
CAP HALL EFFECT
5132382
$47,24 Unit Price incl. VAT
39
SCREW
7517658
$10,49 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
