Parts Catalog
SHROUD
5
Parts Diagram
Parts Catalog
CRANKSHAFT AND PISTON
by
FUEL TANK
SHROUD
26
27
28
29
30
1
32
33
34
34
35
36
37
38
39
40
41
42
43
1
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
2
GAUGE MFD ANALOG/DIGITAL
3280292
$890,39 Unit Price incl. VAT
3
GASKET-MFI
5411738
$8,39 Unit Price incl. VAT
4
CONNECTOR-DEUTCHE 4PIN W/PLUGS
4010281
$27,92 Unit Price incl. VAT
5
PITOT LINE 90DEG FORMED 235CM. Substituted by 8450070-277
8450070235
$35,69 Unit Price incl. VAT
6
SPRING MOUNTING MFI
7041931
$2,93 Unit Price incl. VAT
7
MFI BUTTON REPLACEMENT KIT
2201593
$37,16 Unit Price incl. VAT
8
BEZEL-MFI OVERLAY
3280342
$38,42 Unit Price incl. VAT
9
LID-CONSOLE BLACK MET
54341761093
Not Available
10
SEAL-BULB CONSOLE LID
5521579
Not Available
11
NUT 6 MM. S.S.(10)
7546705
$9,44 Unit Price incl. VAT
12
PAD-CONSOLE
5812235
Not Available
13
SCREW(10)
7517668
$3,35 Unit Price incl. VAT
14
WASHER FLAT S.S.(10)
7555831
Not Available
15
NUT NYLOCK SS.(10)
7546704
$2,82 Unit Price incl. VAT
16
WASHER-6.4MMX18X1.6 SS
7556094
$9,44 Unit Price incl. VAT
17
HOOK-CONSOLE LATCH
5245455
Not Available
18
GASKET-MIRROR LH
5411557
$7,97 Unit Price incl. VAT
18
SCREW (10)
7517669
Not Available
19
MIRROR LH BLACK ASM. (LH)
2631972070
$192,14 Unit Price incl. VAT
19
GASKET-MIRROR RH
5411558
$7,97 Unit Price incl. VAT
20
MIRROR RH BLACK ASM. (RH)
2631973070
$171,66 Unit Price incl. VAT
21
RIVET-POP (50)
7661042
$1,77 Unit Price incl. VAT
22
MOUNT SHROUD
1820725
$23,82 Unit Price incl. VAT
23
NUT-HEX M8X1.25 NYLOCK-SS [S99CR]
7546804
$2,09 Unit Price incl. VAT
24
WASHER FLAT S.S.(10)
7555839
$0,93 Unit Price incl. VAT
25
NUT
7541931
$9,44 Unit Price incl. VAT
26
BRKT SUPPORT SHROUD
5244673
Not Available
27
BOLT(10)
7516807
Not Available
28
GROMMET-DECK WIRE HARNESS
5411664
Not Available
29
STRAP-TOOL KIT LOWER
2690151
Not Available
30
COVER-WIRE SHROUD BLK
5433210070
Not Available
31
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
32
STRAP-TOOL KIT UPPER
2690150
Not Available
33
RING-RETAINING .25 STUD
7710517
Not Available
34
SCREW S.S.(10)
7516805
$1,14 Unit Price incl. VAT
35
WASHER LOCK(10)
7552613
Not Available
36
SHROUD-STEER NO REV BLK MET
54342101093
Not Available
37
BUMPER DOOR/SHROUD
5812076
$15,95 Unit Price incl. VAT
38
PLATE LATCH RECEIVER
5244670
Not Available
39
WASHER FLAT S.S.(10)
7555837
$2,09 Unit Price incl. VAT
40
SCR-#10-32X3/4 FLAT SOC SS(10)
7517879
Not Available
41
PIN-HINGE CONSOLE
5333698
Not Available
42
SPRING-TORTION CONSOLE 070.SS [Item NotAvailable]
7042007
Not Available
43
HINGE-CONSOLE 3/16 PIN
5433384
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
